49
Specifications
Amplifier
Output Power
At Stereo operation
Front ch: 100 W per channel, min. RMS, driven into 8 Ω at
1 kHz, with no more than 0.8% total harmonic
distortion. (IEC 268-3/DIN)
At Surround operation
Front ch: 100 W per channel, min. RMS, driven into 8 Ω at
1 kHz, with no more than 0.8% total harmonic
distortion.
Center ch: 100 W, min. RMS, driven into 8 Ω at 1 kHz, with
no more than 0.8% total harmonic distortion.
Surround ch: 100 W per channel, min. RMS, driven into 8 Ω at
1 kHz, with no more than 0.8% total harmonic
distortion.
Surround Back ch:
100 W, min. RMS, driven into 8 Ω at 1 kHz, with
no more than 0.8% total harmonic distortion.
Audio
Audio Input Sensitivity/Impedance (1 kHz)
PHONO IN (MM): 2.5 mV/47 kΩ
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO IN:
200 mV/47 kΩ
CD IN, CDR IN, TAPE/MD IN: 200 mV/47 kΩ
Audio Input (DIGITAL IN)*
Coaxial: DIGITAL 1 (DVD): 0.5 V(p-p)/75 Ω
Optical:
DIGITAL 2 (CD), DIGITAL 3 (TV), DIGITAL 4 (CDR):
–21 dBm to –15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz).
Audio Output Level: PRE OUT: 1 V
Recording Output Level: VCR 1 OUT, VCR 2 OUT, CDR OUT,
TAPE/MD OUT: 200 mV
Digital output: Optical: DIGITAL OUTPUT
Signal wave length: 660 nm
Output level: –21 dBm to –15 dBm
Signal-to-Noise Ratio (’66 IHF/DIN)
PHONO IN: 70 dB/66 dB
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO:
87 dB/67 dB
CD IN, CDR IN, TAPE/MD IN: 87 dB/67 dB
Frequency Response (8 Ω)
PHONO IN: 20 Hz to 20 kHz (±1 dB)
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO:
20 Hz to 100 kHz (+1 dB, –3 dB)
CD IN, CDR IN, TAPE/MD IN: 20 Hz to 100 kHz (+1 dB, –3 dB)
RIAA Phono Equalization: ±1 dB (20 Hz to 20 kHz)
Equalization (5 bands):
63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz (±8 dB)
Bass boost: +6 dB ±1 dB at 100 Hz
Video
Video Input Sensitivity/Impedance
Composite video:
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO:
1 V(p-p)/75 Ω
S-video:
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO:
(Y: luminance): 1 V(p-p)/75 Ω
(C: chrominance, burst): 0.286 V(p-p)/75 Ω
Component video: DVD IN, DBS IN:
(Y: luminance): 1 V(p-p)/75 Ω
(P
B/PR): 0.7 V(p-p)/75 Ω
Video Output Level
Composite video:
VCR 1 OUT, VCR 2 OUT, MONITOR OUT 1 V(p-p)/75 Ω
S-video: VCR 1 OUT, VCR 2 OUT, MONITOR OUT
(Y: luminance): 1 V(p-p)/75 Ω
(C: chrominance, burst): 0.286 V(p-p)/75 Ω
Component video: MONITOR OUT:
(Y: luminance): 1 V(p-p)/75 Ω
(P
B/PR): 0.7 V(p-p)/75 Ω
Synchronization: Negative
Signal-to-Noise Ratio: 45 dB
FM tuner (IHF)
Tuning Range: 87.50 MHz to 108.00 MHz
Usable Sensitivity: Monaural: 12.8 dBf (1.2 µV/75 Ω)
50 dB Quieting Sensitivity: Monaural: 16.0 dBf (1.7 µV/75 Ω)
Stereo: 37.5 dBf (20.5 µV/75 Ω)
Stereo Separation at REC OUT: 35 dB at 1 kHz
AM tuner
Tuning Range: 531 kHz to 1 602 kHz (at 9 kHz intervals)
530 kHz to 1 600 kHz (at 10 kHz intervals)
General
Power Requirements: AC 110 V/127 V/220 V/230 V – 240 V ,
adjustable with the voltage selector, 50 Hz/60 Hz
Power Consumption: 250 W (at operation)
4.5 W (in standby mode)
Dimensions (W x H x D): 435 mm x 157 mm x 425 mm
12.3 kg
Designs & specifications are subject to change without notice.
