JVC RX-8040B User Manual

12
MONITOR
OUT
TV SOUND
DBS
IN
MONITOR
OUT
Y
PB
PR
A
B
C
D
R
L
TV and/or DBS tuner
Å To audio output
ı To component video input
Ç To S-video input
Î To composite video input
Å To audio output
ı To component video output
Ç To S-video output
Î To composite video output
Notes:
• When connecting a DBS tuner to the TV SOUND/DBS IN jacks,
change the source name to “DBS,” which will appear on the display
when it is selected as the source. Otherwise, you cannot view any
picture from DBS tuner. See page 24 for details.
• When connecting a DBS tuner to component video input jacks,
make the component video input setting (VIDEO IN DBS) correctly.
See page 38 for details.
TV
When connecting
the TV to the
AUDIO jacks (TV
SOUND/DBS IN),
DO NOT connect
the TV’s video
output to these
video input jacks.
Connect the TV to appropriate MONITOR OUT jacks to view
the playback picture from any other connected video
components.
DBS
IN
(VCR1)
TV SOUND
DBS
IN
A
B
C
D
R
L
DBS
VCR(s)
You can connect two VCRs—one to the VCR 1 jacks and the other
to the VCR 2 jacks.
• If your VCR has an AV COMPU LINK jack, connect it to the
VCR 1 jacks so that you can use the AV COMPU LINK remote
control system.
Å To audio input
ı To audio output
Ç To S-video output
Î To composite video output
‰ To S-video input
Ï To composite video input
Ì To component video output
Note:
When connecting a VCR to component video input jacks, make the
component video input setting (VIDEO IN VCR1) correctly. See page
38 for details.
VCR 1
IN
(PLAY)
OUT
(REC)
A B
D
C
E
F
R
L
R
L
G
DBS
IN
(VCR1)
VCR 2
IN
(PLAY)
OUT
(REC)
VCR
Right / Left
Right / Left
Right / Left
DBS tuner
1-15_8040[J]_D.p65 04.4.21, 11:5212
