JVC RX-8040B - Setting the Digital Input Terminals

37
Setting the digital input terminals
When you use the digital input terminals, register which components
you have connected to the digital input terminals.
7
Digital coaxial terminal—DGTL IN COAX
Set the component connected to the digital coaxial terminal
(DIGITAL 1).
Following setting is available:
• DVD (initial setting)
• CD
• TV (or DBS*
1
)
• CDR
• MD
• VCR*
2
7 Digital optical terminals—DGTL IN OPTICAL
Set the components connected to the digital optical terminals
(DIGITAL 2 – 4).
• As you turn MULTI JOG, the digital optical input terminals
are set to used for following digital components:
When “DIGITAL 1 (DGTL IN COAX)” is set to “DVD”:
2: CD 3: TV (or DBS*
1
) 4: CDR “
2: CD 3: TV (or DBS*
1
) 4: MD “
2: CD 3: TV (or DBS*
1
) 4: VCR*
2
“
2: CD 3: MD 4: CDR “
2: CD 3: MD 4: VCR*
2
“
2: CD 3: VCR*
2
4: CDR “
2: MD 3: TV (or DBS*
1
) 4: CDR “
2: MD 3: TV (or DBS*
1
) 4: VCR*
2
“
2: MD 3: VCR*
2
4: CDR “
2: VCR*
2
3: TV (or DBS*
1
) 4: CDR “
(back to the beginning)
When “DIGITAL 1 (DGTL IN COAX)” is set to “CD”:
2: DVD 3: TV (or DBS*
1
) 4: CDR “
2: DVD 3: TV (or DBS*
1
) 4: MD “
2: DVD 3: TV (or DBS*
1
) 4: VCR*
2
“
2: DVD 3: MD 4: CDR “
2: DVD 3: MD 4: VCR*
2
“
2: DVD 3: VCR*
2
4: CDR “
2: MD 3: TV (or DBS*
1
) 4: CDR “
2: MD 3: TV (or DBS*
1
) 4: VCR*
2
“
2: MD 3: VCR*
2
4: CDR “
2: VCR*
2
3: TV (or DBS*
1
) 4: CDR “
(back to the beginning)
When “DIGITAL 1 (DGTL IN COAX)” is set to “TV” or
“DBS”*
1
:
2: CD 3: DVD 4: CDR “
2: CD 3: DVD 4: MD “
2: CD 3: DVD 4: VCR*
2
“
2: CD 3: MD 4: CDR “
2: CD 3: MD 4: VCR*
2
“
2: CD 3: VCR*
2
4: CDR “
2: MD 3: DVD 4: CDR “
2: MD 3: DVD 4: VCR*
2
“
2: MD 3: VCR*
2
4: CDR “
2: VCR*
2
3: DVD 4: CDR “
(back to the beginning)
When “DIGITAL 1 (DGTL IN COAX)” is set to “CDR”:
2: CD 3: TV (or DBS*
1
)4: DVD “
2: CD 3: TV (or DBS*
1
) 4: MD “
2: CD 3: TV (or DBS*
1
) 4: VCR*
2
“
2: CD 3: MD 4: DVD “
2: CD 3: MD 4: VCR*
2
“
2: CD 3: VCR*
2
4: DVD “
2: MD 3: TV (or DBS*
1
)4: DVD “
2: MD 3: TV (or DBS*
1
) 4: VCR*
2
“
2: MD 3: VCR*
2
4: DVD “
2: VCR*
2
3: TV (or DBS*
1
)4: DVD “
(back to the beginning)
When “DIGITAL 1 (DGTL IN COAX)” is set to “MD”:
2: CD 3: TV (or DBS*
1
) 4: CDR “
2: CD 3: TV (or DBS*
1
)4: DVD “
2: CD 3: TV (or DBS*
1
) 4: VCR*
2
“
2: CD 3: DVD 4: CDR “
2: CD 3: DVD 4: VCR*
2
“
2: CD 3: VCR*
2
4: CDR “
2: DVD 3: TV (or DBS*
1
) 4: CDR “
2: DVD 3: TV (or DBS*
1
) 4: VCR*
2
“
2: DVD 3: VCR*
2
4: CDR “
2: VCR*
2
3: TV (or DBS*
1
) 4: CDR “
(back to the beginning)
When “DIGITAL 1 (DGTL IN COAX)” is set to “VCR*
2
”:
2: CD 3: TV (or DBS*
1
) 4: CDR “
2: CD 3: TV (or DBS*
1
) 4: MD “
2: CD 3: TV (or DBS*
1
)4: DVD “
2: CD 3: MD 4: CDR “
2: CD 3: MD 4: DVD “
2: CD 3: DVD 4: CDR “
2: MD 3: TV (or DBS*
1
) 4: CDR “
2: MD 3: TV (or DBS*
1
)4: DVD “
2: MD 3: DVD 4: CDR “
2: DVD 3: TV (or DBS*
1
) 4: CDR “
(back to the beginning)
*
1
If you have changed the source name from “TV” to “DBS,”
“DBS” appears (see page 24).
*
2
“VCR” on the DGTL IN COAX and DGTL IN OPTICAL setting
menu means VCR1.
