JVC RX-D301S Service Manual

1-2 (No.MB479)
SPECIFICATION
*2: Corresponding to Linear PCM, Dolby Digital, and DTS (with sampling frequency -32 kHz, 44.1 kHz, 48 kHz).
Designs and specifications are subject to change without notice.
Amplifier
Output Power At stereo operation Front channels 110 W per channel, min. RMS, driven into 6
Ω at
1 kHz with no more than 0.8% total harmonic dis-
tortion.
At surround operation Front channels 110 W per channel, min. RMS, driven into 6
Ω at
1 kHz with no more than 0.8% total harmonic dis-
tortion.
Center channel 110 W, min. RMS, driven into 6
Ω at 1 kHz, with
no more than 0.8% total harmonic distortion.
Surround channels 110 W per channel, min. RMS, driven into 6
Ω at
1 kHz with no more than 0.8% total harmonic dis-
tortion.
Surround back channels 110 W per channel, min. RMS, driven into 6
Ω at
1 kHz with no more than 0.8% total harmonic dis-
tortion.
Audio Audio Input Sensitivity/Impedance DVR/DVD (DVD MULTI), VCR, DBS, TV 270 mV/47 k
Ω
Audio Input (DIGITAL IN)*1 Coaxial: DIGITAL IN 1(DVR/DVD) 0.5 V(p-p)/75 Ω
Optical: DIGITAL IN 2(DBS), 3(VCR) -21 dBm to -15 dBm (660 nm ±30 nm)
USB: USB WIRELESS USB TERMINAL
Audio Output Level DVR, VCR 270 mV
Signal-to-Noise Ratio ('66 IHF/'78 IHF) 80 dB/62 dB
Frequency Response (6
Ω) 20 Hz to 20 kHz (±1 dB)
Bass Boost +4 dB ±1 dB at 100 Hz
Equalization (at DSP operation) Center frequency 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz
Control range ±8 dB
Video Video Input Sensitivity/Impedance Composite video: DVR/DVD, VCR, DBS 1 V(p-p)/75
Ω
S-video: DVR/DVD, VCR, DBS Y (luminance): 1 V(p-p)/75 Ω
C (chrominance, burst): 0.3 V(p-p)/75 Ω
Component: DVR/DVD, VCR (DBS) Y (luminance): 1 V(p-p)/75 Ω
PB, PR: 0.7 V(p-p)/75 Ω
Video Output Level/Impedance Composite video: DVR, VCR, MONITOR OUT 1 V(p-p)/75 Ω
S-video: DVR, VCR, MONITOR OUT Y (luminance): 1 V(p-p)/75 Ω
C (chrominance, burst): 0.3 V(p-p)/75 Ω
Component: MONITOR OUT Y (luminance): 1 V(p-p)/75 Ω
PB, PR: 0.7 V(p-p)/75 Ω
Synchronization Negative
FM tuner (IHF)
Tuning Range 87.50 MHz to 108.00 MHz
Usable Sensitivity Monaural 12.8 dBf (1.2 µV/75 Ω) for A version
17.0 dBf (1.9 µV/75 Ω) for Europe version
50 dB Quieting Sensitivity Monaural 16.0 dBf (1.7 µV/75 Ω) for A version
21.3 dBf (3.2 µV/75 Ω) for Europe version
Stereo 37.5 dBf (20.5 µV/75 Ω) for A version
41.3 dBf (31.8 µV/75 Ω) for Europe version
Stereo Separation at REC OUT 35 dB at 1 kHz
AM tuner
Tuning Range 531 kHz to 1 710 kHz (at 9 kHz intervals)
522 kHz to 1 629 kHz (at 10 kHz intervals)
General
Power Requirements AC 240 V ,50 Hz for A version
AC 230 V , 50 Hz for Europe version
Power Consumption 180 W (at operation)
5.8 W (in standby mode) for A version
0.9 W (in standby mode) for Europe version
Dimensions (W
× H × D) 435 mm × 91.5 mm × 371 mm
Mass 6.8 kg
USB WIRELESS SYSTEM The USB wireless transmitter supplied with this re-
ceiver supports Direct Sequence Spreading Spec-
trum (DSSS) using 2.4 GHz frequency band.
