JVC RX-D301S Service Manual

3-8
Amplifier board
Block No. [0][2]
R1163 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R1164 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1165 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1166 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R1169 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1170 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R1172 NRSA02J-332X MG RESISTOR 3.3k
Ω 1/10W J
R1173 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R1174 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R1175 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1176 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1178 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R1179 NRSA63F-332X MG RESISTOR 3.3k Ω 1/16W F
R1180 NRSA63J-133X MG RESISTOR 13k Ω 1/16W J
R1181 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
 R1295 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
 R1391 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
 R1491 QRJ146J-470X UNF C RESISTOR 47 Ω 1/4W J
R6595 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J D301SA
 T102 QQT0281-006 POWER TRANSF D301SA
 T102 QQT0478-002 POWER TRANSF
D301SB,D301SE,
D301SEN,D302BB,
D302BE,D302BEN
BK901 LV34673-001A FL HOLDER(L)
BK902 LV34687-001A FL HOLDER(R)
CN120 QGA7901C1-02 CONNECTOR W-B (1-2)
CN151 QGB2510K1-12 CONNECTOR B-B (1-12)
CN202 QJK002-071802-E SIN CR C-B WIRE
CN206 WJK0208-002A-E E-SI C WIRE C-B
CN209 QGA2501C1-06 CONNECTOR W-B (1-6)
CN211 QJK012-033803-E SIN CR C-B WIRE
CN262 QGA3901C1-08 CONNECTOR W-B (1-8)
CN265 QGA3901C1-06 CONNECTOR W-B (1-6)
CN465 QGA2001C1-03 CONNECTOR W-B (1-3)
CN524 QGA2501C1-02 CONNECTOR W-B (1-2)
CN565 QGA2501C1-02 CONNECTOR W-B (1-2) D301SA
CN591 QGB2510K1-09 CONNECTOR B-B (1-9) D301SA
CN592 QGB2510K1-09 CONNECTOR B-B (1-9) D301SA
CN593 QGB2510K1-11 CONNECTOR B-B (1-11) D301SA
CN594 QGB2510K1-11 CONNECTOR B-B (1-11) D301SA
CN902 QGF1205F1-05 CONNECTOR FFC/FPC (1-5)
CN903 QJK021-070802-E SIN CR C-B
CN913 QGA2001F1-07 CONNECTOR W-B (1-7)
CN914 QGA2001F1-03 CONNECTOR W-B (1-3)
CN952 QJK021-124402-E SIN CR C-B WIRE
DI901 QLF0157-001 FL TUBE
EP151 QNZ0136-001Z EARTH PLATE
FC103 QNG0020-001Z FUSE CLIP
FC104 QNG0020-001Z FUSE CLIP
FC113 QNG0020-001Z FUSE CLIP
FC114 QNG0020-001Z FUSE CLIP
FS181 VYSH101-009 SPACER
FS900 VYSH101-009 SPACER
FS901 VYSH101-009 SPACER
FW121 WJS0047-002A-E E-FL/RB WIRE
FW451 WJS0046-003A-E E-FL/RB WIRE
J504 QNN0480-001 PIN JACK
J505 QNS0089-001 3.5 JACK D301SA
JS901 QSW1129-001
ROTARY
ENCODER
JS902 QSW1129-001
ROTARY
ENCODER
RY101 QSK0142-001 RELAY D301SA
 RY101 QSK0128-001 RELAY
D301SB,D301SE,
D301SEN,D302BB,
D302BE,D302BEN
 RY295 QSK0127-001 RELAY
 RY391 QSK0127-001 RELAY
 RY491 QSK0127-001 RELAY
 RY895 QSK0127-001 RELAY
S901 QSW0683-001Z PUSH SW
S902 QSW0683-001Z PUSH SW
S903 QSW0683-001Z PUSH SW
S904 QSW0683-001Z PUSH SW
S905 QSW0683-001Z PUSH SW
S906 QSW0683-001Z PUSH SW
ST292 QNB0256-001 IC
 Symbol No. Part No. Part Name Description Local
ST295 QNB0079-001 SPK TERMINAL
X241 QAX0734-001 C RESONATOR 400.00kHz
X242 QAX0735-001 C RESONATOR 420.00kHz
X901 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC101 IRS2011S-X IC
 IC151 KIA7805API IC
 IC152 KIA7809API IC
 IC153 KIA7805API IC
IC201 JCV8015-X IC
IC202 SN74LVC3G04T-X IC
IC251 IRS20124S-X IC
IC261 IRS20124S-X IC
IC301 JCV8015-X IC
IC302 SN74LVC3G04T-X IC
IC351 IRS20124S-X IC
IC361 IRS20124S-X IC
IC401 JCV8015-X IC
IC451 IRS20124S-X IC
IC461 IRS20124S-X IC
IC801 JCV8015-X IC
IC851 IRS20124S-X IC
 Q101 KTD863/Y/-T TRANSISTOR
 Q102 KTA1046/Y/ TRANSISTOR
Q103 KTC3200/GL/-T TRANSISTOR
Q151 KRA102S-X DIGI TRANSISTOR
Q152 KRC102S-X DIGI TRANSISTOR
 Q153 2SD2394/EF/ TRANSISTOR
Q154 KRC102S-X DIGI TRANSISTOR
 Q157 2SD2394/EF/ TRANSISTOR
 Q158 KTA1046/Y/ TRANSISTOR
Q161 KRC111S-X TRANSISTOR
Q162 KRC111S-X TRANSISTOR
Q163 KRC111S-X TRANSISTOR
 Q171 2SD2394/EF/ TRANSISTOR
 Q173 2SD2394/EF/ TRANSISTOR D301SA
 Q174 2SD2394/EF/ TRANSISTOR
 Q175 2SD2394/EF/ TRANSISTOR
Q201 KTA1268/GL/-T TRANSISTOR
Q211 KTC3875/YG/-X SI TRANSISTOR
Q214 KRC102M-T DIGI TRANSISTOR
Q251 KTA1504/YG/-X SI TRANSISTOR
Q261 IRFB4212 FET
Q262 IRFB4212 FET
Q281 KRC109M-T DIGI TRANSISTOR
Q282 KRA102M-T DIGI TRANSISTOR
Q283 KTC3200/GL/-T TRANSISTOR
Q284 KTA1268/GL/-T TRANSISTOR
Q285 KTC3199/GL/-T TRANSISTOR
Q286 KRC102M-T DIGI TRANSISTOR
Q301 KTA1268/GL/-T TRANSISTOR
Q351 KTA1504/YG/-X SI TRANSISTOR
Q361 IRFB4212 FET
Q362 IRFB4212 FET
Q401 KTA1268/GL/-T TRANSISTOR
Q451 KTA1504/YG/-X SI TRANSISTOR
Q461 IRFB4212 FET
Q462 IRFB4212 FET
Q801 KTA1268/GL/-T TRANSISTOR
Q851 KTA1504/YG/-X SI TRANSISTOR
Q861 IRFB4212 FET
Q862 IRFB4212 FET
 Q1101 2SK3599-01MR POWER MOS FET
 Q1102 2SK3599-01MR POWER MOS FET
Q1104 KTA1268/GL/-T TRANSISTOR
Q1201 KTA1268/GL/-T TRANSISTOR
Q1251 KTA1504/YG/-X SI TRANSISTOR
Q1261 IRFB4212 FET
 Symbol No. Part No. Part Name Description Local
