JVC RX-D301S Service Manual

3-22
Input board (A ver.)
Block No. [0][4]
CN540 QGA2001C1-06 CONNECTOR W-B (1-6)
CN552 QGA2001C1-12 CONNECTOR W-B (1-12)
CN555 QGA2501C1-02 CONNECTOR W-B (1-2)
CN661 QGA2501F1-03 CONNECTOR W-B (1-3)
CN662 QGA2501F1-05 CONNECTOR W-B (1-5)
CN681 QGB2510J1-07 CONNECTOR B-B (1-7)
CN682 QGA2001F1-06 CONNECTOR W-B (1-6)
CN683 QGA2501F1-09 CONNECTOR W-B (1-9)
CN904 QJK021-031203-E WIRE
CN905 QJP001-032603-E WIRE
CN961 QJP001-034203-E WIRE
EP11 E409182-001SM GRAND TERMINAL
EP12 E409182-001SM GRAND TERMINAL
EP681 E409182-001SM GRAND TERMINAL
EP682 QNZ0136-001Z EARTH PLATE
EP901 QNZ0136-001Z EARTH PLATE
FL501 QQR1372-001 LPF
FL502 QQR1372-001 LPF
FW501 WJS0048-003A-E E-FL/RB WIRE
J681 QNN0481-001 SURROUND JACK
J901 QNS0247-001 JACK
J903 QNZ0783-002 USB CONNECTOR
J4503 QNN0681-001 PIN JACK
J6503 QNN0476-001 PIN JACK
J6504 QNN0690-001 PIN JACK
J8511 QNZ0625-001 RGB CONNECTOR
J8512 QNZ0625-001 RGB CONNECTOR
J8513 QNN0557-002 PIN JACK
J9511 QNZ0625-001 RGB CONNECTOR
K2801 NQR0007-003X FERRITE BEADS
K2802 NQR0007-003X FERRITE BEADS
K2803 NQR0007-003X FERRITE BEADS
K2804 NQR0007-003X FERRITE BEADS
K2861 NQR0269-004X FERRITE BEADS
K4501 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
SW11 QSW0454-001 SW
UN682 TORX177 OPT RECEIVER
UN683 TORX177 OPT RECEIVER
UN686 TOTX177 OPT RECEIVER
X501 QAX0246-001Z C RESONATOR 8.00MHz
X502 QAX0263-001Z CRYSTAL 4.332MHz
X661 QAX0722-001Z CRYSTAL 24.576MHz
X671 QAX0719-001Z C RESONATOR 6.144MHz
X905 QAX0320-001Z CRYSTAL 12.000MHz
X5505 QAX0879-001Z CRYSTAL
 Symbol No. Part No. Part Name Description Local
IC11 DIT4096IPW-X IC(DIGITAL)
IC501 MN101C49GNP IC(MCU)‹›¿ð—106
IC502 BD3843FS-X IC
IC503 BD3813KS IC
IC504 NJM4565M-WE IC
IC506 IC-PST9139-T IC
IC507 BR24L01AF-W-X IC
IC508 BD3812F-X IC
IC522 MM1117XF-XE IC
IC524 MM1501XN-X IC
IC525 MM1501XN-X IC
IC527 MM1118XF-X IC
IC530 MM1504XN-X IC
IC531 MM1506XN-X IC
IC532 MM1506XN-X IC
IC536 MM1502XN-X IC
IC537 MM1504XN-X IC
IC551 TC90A49AP IC
IC559 MM1093NF-X IC
IC601 NJM4565M-WE IC
IC602 NJM4565M-WE IC
IC611 NJM4565M-WE IC
IC612 NJM4565M-WE IC
 Symbol No. Part No. Part Name Description Local
IC613 NJM4565M-WE IC
IC614 NJM4565M-WE IC
IC621 NJM4565M-WE IC
IC622 NJM4565M-WE IC
IC631 NJM2120M-X IC
IC632 NJM4565M-WE IC
IC633 NJM4565M-WE IC
IC634 NJM4565M-WE IC
IC651 NJM4565M-WE IC
IC652 NJM4565M-WE IC
IC661 DSPC56371AF180 IC
IC662 SN74AHC2GU04T-X IC
IC667 CS42518-CQZ-C-W IC
IC671 UPD784215AGC284 IC
IC672 SN74AHCT1G32K-X IC
IC673 SN74LVC1G04K-X IC
IC681 JCV8009-W IC
IC682 MN35505-X IC
IC683 SN74AHC2G74T-X IC
IC684 SN74LVC2G241T-X IC
IC691 BD7800FP-X IC
IC692 MM1563DF-X IC
IC903 PCM2704DB-X IC
IC904 SN74AHC1G08V-X IC
Q501 2SC3576-JVC-T TRANSISTOR
Q502 2SC3576-JVC-T TRANSISTOR
Q503 KRA104S-X DIGI TRANSISTOR
Q510 KRC102S-X DIGI TRANSISTOR
Q511 KRA104S-X DIGI TRANSISTOR
Q512 KRA104S-X DIGI TRANSISTOR
Q513 2SC3576-JVC-T TRANSISTOR
Q514 2SC3576-JVC-T TRANSISTOR
Q515 2SC3576-JVC-T TRANSISTOR
Q516 2SC3576-JVC-T TRANSISTOR
Q517 2SC3576-JVC-T TRANSISTOR
Q518 2SC3576-JVC-T TRANSISTOR
Q519 2SC3576-JVC-T TRANSISTOR
Q521 2SC3576-JVC-T TRANSISTOR
Q522 2SC3576-JVC-T TRANSISTOR
Q523 KRA104S-X DIGI TRANSISTOR
Q524 KTC3875/YG/-X SI TRANSISTOR
Q525 2SC3576-JVC-T TRANSISTOR
Q526 2SC3576-JVC-T TRANSISTOR
Q541 KTC3199/GL/-T TRANSISTOR
Q542 KTC3199/GL/-T TRANSISTOR
Q1501 2SC2412K/RS/-X TRANSISTOR
Q2101 2SD2114K/VW/-X TRANSISTOR
Q2102 2SD2114K/VW/-X TRANSISTOR
Q2141 2SC3928A/RS/-X TRANSISTOR
Q2142 2SC3928A/RS/-X TRANSISTOR
Q2201 2SD2114K/VW/-X TRANSISTOR
Q2202 2SD2114K/VW/-X TRANSISTOR
Q2221 2SD2114K/VW/-X TRANSISTOR
Q2222 2SD2114K/VW/-X TRANSISTOR
Q2223 2SD2114K/VW/-X TRANSISTOR
Q2224 2SD2114K/VW/-X TRANSISTOR
Q2301 2SD2114K/VW/-X TRANSISTOR
Q2341 2SC3928A/RS/-X TRANSISTOR
Q2401 2SD2114K/VW/-X TRANSISTOR
Q2421 2SD2114K/VW/-X TRANSISTOR
Q2422 2SD2114K/VW/-X TRANSISTOR
Q2501 2SD2114K/VW/-X TRANSISTOR
Q2502 2SD2114K/VW/-X TRANSISTOR
Q2701 KRC107S-X DIGI TRANSISTOR
Q2702 KRC107S-X DIGI TRANSISTOR
Q2703 KRC107S-X DIGI TRANSISTOR
Q2704 KRA107S-X DIGI TRANSISTOR
Q2705 KRA107S-X DIGI TRANSISTOR
Q2706 KRA107S-X DIGI TRANSISTOR
Q2708 KRA107S-X DIGI TRANSISTOR
Q2709 KRA107S-X DIGI TRANSISTOR
Q2710 KRC107S-X DIGI TRANSISTOR
Q4501 KTA1267/YG/-T TRANSISTOR
Q4502 KTA1267/YG/-T TRANSISTOR
Q4503 KRA120S-X TRANSISTOR
Q4521 2SA1037AK/RS/-X TRANSISTOR
Q4522 2SC2412K/RS/-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
