JVC RX-DP20VBK Service Manual

1-2 (No.22008)
SPECIFICATION
Amplifier Output Power At Stereo operation
(Analog Direct On)
Front channels
120 W per channel, min. RMS, driven into 8 Ω, 20 Hz to 20 kHz with no more
than 0.02% total harmonic distortion. 120 W per channel, min. RMS, driven
into 4 Ω, 20 Hz to 20 kHz with no more than 0.07% total harmonic distortion.
At Surround operation
(Analog Direct On)
Front channels
120 W per channel, min. RMS, driven into 8 Ω, 20 Hz to 20 kHz with no more
than 0.02% total harmonic distortion.
Center channel
120 W, min. RMS, driven into 8 Ω, 20 Hz to 20 kHz with no more than 0.02%
total harmonic distortion.
Surround channels
120 W per channel, min. RMS, driven into 8 Ω, 20 Hz to 20 kHz with no more
than 0.02% total harmonic distortion.
Surround back channels
120 W per channel, min. RMS, driven into 8 Ω, 20 Hz to 20 kHz with no more
than 0.02% total harmonic distortion.
Audio Audio Input
Sensitivity
/Impedance
(1 kHz)
PHONO IN (MC) 0.25 mV/100 Ω
(MM) 2.5 mV/47 kΩ
CD IN, CDR IN, TAPE/MD IN, EXT 7.1CH IN 200 mV/47 kΩ
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO 200 mV/47 kΩ
Audio Input
(DIGITAL IN)*
Coaxial 1(DVD), 2(CD), 3(TV/DBS) 0.5 V(p-p)/75 Ω
Optical 4(CDR), 5(MD), 6(VCR1) -21 dBm to -15 dBm (660 nm ±30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround
(with sampling frequency - 32 kHz, 44.1 kHz, 48 kHz)
Audio Output Level ZONE 2 PREOUT 200 mV
PREOUT 1 V
Recording Output
Level
TAPE/MD OUT, CDR OUT, VCR 1
OUT, VCR 2 OUT
200 mV
Digital output Optical DIGITAL OUT
Signal wave length 660 nm
Output level
Signal-to-Noise Ratio
(‘66 IHF/’78 IHF)
(Analog Direct On)
PHONO IN (MC) 60 dB/72 dB (at REC OUT)
(MM) 72 dB/80 dB (at REC OUT)
CD IN, CDR IN, TAPE/MD IN, EXT 7.1CH IN 92 dB/80 dB
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO 92 dB/80 dB
Frequency Response
(8 Ω)
PHONO IN (MC) 20 Hz to 20 kHz (±1 dB)
(MM) 20 Hz to 20 kHz (±1 dB)
CD IN, CDR IN, TAPE/MD IN, EXT 7.1CH IN 10 Hz to 100 kHz (+1 dB, -3 dB)
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO 10 Hz to 100 kHz (+1 dB, -3 dB)
RIAA Phono Equalization ±1.0 dB (20 Hz to 20 kHz)
Video Video Input
Sensitivity
/Impedance
Composite video
DVD IN, VCR 1 IN, VCR 2 IN, TV SOUND/DBS IN, VIDEO
1 V(p-p)/75 Ω
S-video
DVD IN, VCR 1 IN, VCR 2 IN, TV
SOUND/DBS IN, VIDEO
(Y: luminance) 1 V(p-p)/75Ω
(C: chrominance, burst) 0.286 V(p-p)/75 Ω
Component
1 IN (DVD), 2 IN,3 IN
(Y: luminance) 1 V(p-p)/75 Ω
(PB, PR) 0.7 V(p-p)/75 Ω
Video Output
Level
Composite video
VCR 1 OUT,VCR 2 OUT,MONITOR OUT
1 V(p-p)/75 Ω
S-video
VCR 1 OUT, VCR 2 OUT, MON-
ITOR OUT
(Y: luminance) 1 V(p-p)/75Ω
(C: chrominance, burst) 0.286 V(p-p)/75 Ω
Component
MONITOR OUT
(Y: luminance) 1 V(p-p)/75 Ω
(PB, PR): 0.7 V(p-p)/75 Ω
Synchronization Negative
Signal-to-Noise Ratio 45 dB
