(No.22008)1-3
Designs & specifications are subject to change without notice.
FM tuner
(IHF)
Tuning Range 87.5 MHz to 108.0 MHz
Usable Sensitivity Monaural 12.8 dBf (1.2 µV/75 Ω)
50 dB Quieting Sensitivity Monaural 18.2 dBf (2.2 µV/75 Ω)
Stereo 38.2 dBf (22.3 µV/75 Ω)
Signal-to-Noise Ratio (IHF-A weighted) Monaural 78 dB at 85 dBf
Stereo 73 dB at 85 dBf
Total Harmonic Distortion Monaural 0.2% at 1 kHz
Stereo 0.3% at 1 kHz
Stereo Separation at REC OUT 40 dB at 1 kHz
Alternate Channel Selectivity 60 dB (±400 kHz)
Frequency Response 30 Hz to 15 kHz (+0.5 dB, -3 dB)
AM tuner Tuning Range 530 kHz to 1 710 kHz
Usable Sensitivity Loop antenna: 400 µV/m
Signal-to-Noise Ratio 50 dB (100 mV/m)
General Power Requirements AC 120V~, 60 Hz
Power Consumption 580 W/690 VA (at operation)
2.7 watts (in standby mode)
Dimensions (W × H × D) 445 mm × 177 mm × 475 mm
(17 9/16 in. × 7 in. × 18 3/4 in.)
Mass 23.5 kg (52 lbs)
