JVC RX-DP20VBK Service Manual

3-4
General assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 LV10535-020A FRONT PANEL
2 EXO150010H09S11 FELT SPACER
3 LV10536-024A FRONT BASE
4 LV30225-0D5A SPACER
5 PQ45130-1-1 JVC MARK
6 E60912-003 SPEED NUT
7 LV43263-001A K2 MARK
8 E408131-002 REMOTE LENS
9 LV42395-001A INDICATOR
10 LV32831-002A GUIDE(L)
11 LV32832-002A GUIDE(R)
12 QYSDSF2608M TAPPING SCREW 2.6mm x 8mm(x4)
13 LV32812-002A PUSH BUTTON
14 LV32813-003A PUSH BUTTON
15 LV32826-003A INDICATOR (x3)
16 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
17 LV32815-006A PUSH BUTTON
18 LV32816-004A PUSH BUTTON
19 LV32817-006A PUSH BUTTON
20 LV32818-004A PUSH BUTTON
21 LV32814-002A PUSH BUTTON
22 FSYS4004-004 WASHER
23 QYSDSF2608Z SCREW 2.6mm x 8mm(x9)
24 LV42684-001A BARRIER
25 E310243-002 PLASTIC RIVET
26 E65923-003 TAPP NG SCREW
27 QYSDSF2608Z SCREW 2.6mm x 8mm(x3)
28 LV32811-008A LENS
29 LV42095-003A FL SCREEN
30 LV42405-002A VOL RING
31 LV42726-002A VOL.SPACER
32 LV21375-001A S DE FITTING(L)
33 LV21376-001A S DE FITTING(R)
34 QYSBSF3008Z SCREW 3mm x 8mm(x6)
35 LV21061-007A DOOR
36 LV21062-004A DOOR BASE
37 LV21065-002A PUSH BUTTON (x2)
38 WJT0073-001A E-CARD W RE
39 LV30225-074A SPACER
40 QYSDSF2004Z SCREW 2mm x 4mm(x6)
41 QYSSSG2004Z SCREW 2mm x 4mm(x8)
42 QYSSSG2004Z SCREW 2mm x 4mm(x2)
43 QYSDSF2606Z SCREW 2.6mm x 6mm(x3)
44 LV32835-002A GP. BKT(L)ASSY
45 LV32836-002A GP.BKT(R)ASSY
46 QYSDSF2606Z SCREW 2.6mm x 6mm(x4)
47 LV42478-001A WORM GEAR
48 LV32837-002A MOTOR BASE
49 LV41536-201A PULLEY
50 LV41598-001A BELT
51 LV32838-001A WORM WHEEL
52 QAR0100-001 DC MOTOR
53 WJM0233-001A E-SI C WIRE C-F
54 QYSPSP3004Z SCREW M3 x 4mm(x2)
55 LV32830-001A MAIN SHAFT
56 LV42400-001A MAIN GEAR
57 LV42729-002A SPRING
58 QYREE3000X E RING M3
59 LV32833-002A H.BKT(L) ASSY
60 LV32834-002A H.BKT(R) ASSY
61 LV42396-002A ARM (x2)
62 QYREE3000X E RING M3(x2)
63 QYREE6000X E RING M6(x4)
64 LV42397-001A S.STOPPER(L)
65 QYSDSG2606Z SCREW 2.6mm x 6mm
66 LV42398-001A S.STOPPER(R)
67 LV32839-001A WHEEL STOPPER
68 QYSBSF3008Z SCREW 3mm x 8mm(x3)
69 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
70 QYSDSF2606M SCREW 2.6mm x 6mm(x4)
71 LV42783-001A EARTH PLATE
72 LV43235-004A SHEET
73 LV10537-005A BOTTOM PLATE
74 QZF6018-001 FOOT 60mm x 18mm(x4)
75 QYSBST3010Z TAPP NG SCREW M3 x 10mm(x4)
76 LV10541-003A SIDE BKT(L)
77 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x4)
78 LV10542-004A TRANS BASE
79 QYSDSG3008E TAPP NG SCREW 3mm x 8mm(x10)
80 LV10543-003A CENTER BKT(L)
81 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x5)
82 LV10544-002A CENTER BKT(R)
83 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x5)
84 LV21066-002A SIDE BKT(R)
85 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x4)
86 LV10539-003A FRONT BKT
87 LV41603-001A LEAF SPRING
88 QYSBSG3008E TAPP NG SCREW 3mm x 8mm
89 LV30225-071A SPACER (x4)
90 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x9)
91 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x5)
92 LV30225-0C8A SPACER
93 E310243-002 PLASTIC RIVET (x3)
94 LV43600-001A H.P.JACK BKT
95 QYSBSGG3006Z SCREW 3mm x 6mm
96 VKZ4150-001 SPECIAL NUT
97 QYSDSG3008E TAPP NG SCREW 3mm x 8mm(x3)
98 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x4)
99 LV32828-006A HEAT SINK (x2)
 100 2SC3858/PG/-F1 TRANSISTOR
Q714 Q764 Q814
Q1614 Q1664
Q1714 Q1764(x7)
 101 2SA1494/PG/-F1 TRANSISTOR
Q715 Q765 Q815
Q1615 Q1665
Q1715 Q1765(x7)
102 E73525-003SS SCREW (x28)
103 QYSBSGG3010E TAPP NG SCREW 3mm x 10mm(x7)
104 QYSBSGG3010E TAPP NG SCREW 3mm x 10mm(x4)
105 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
106 QYSBSGG3010E TAPP NG SCREW 3mm x 10mm(x2)
107 LV30225-0D3A SPACER
108 LV21067-002A H.SINK BKT (x2)
109 LV30225-071A SPACER
110 LV30225-074A SPACER (x3)
111 QYSBSGG3010E TAPP NG SCREW 3mm x 10mm(x8)
112 QYSBSG3010E TAPP NG SCREW 3mm x 10mm
113 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x4)
114 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x4)
115 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x7)
116 E310244-003 FASTENER (x4)
117 LV30225-0P2A SPACER
118 LV30225-0N9A SPACER
119 LV21068-003A SHIELD COVER
120 LV30225-0N9A SPACER
121 LV30225-0D4A SPACER (x2)
122 LV30226-034A SPACER (x2)
123 E310243-002 PLASTIC RIVET (x2)
124 QYSBSGG3008E TAPPING SCREW 3mm x 8mm
125 LV30225-0P1A SPACER
126 LV30225-0P3A SPACER
127 E310243-002 PLASTIC RIVET
128 LV30225-0C7A SPACER
129 QAU0233-001 TUNER
130 QAU0237-002 TUNER
131 E310244-003 FASTENER
132 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x4)
133 LV30225-074A SPACER
134 QYSBSGG3008E TAPP NG SCREW 3mm x 8mm(x6)
 135 QQT0378-001 POWER TRANSF T 41
136 QYSDSTL4008E TAP SCREW M4 x 8mm(x2)
 137 QQT0379-001 POWER TRANSF T 42
138 LV43364-001A BARRIER (x2)
139 QYSDSTL4008E TAP SCREW M4 x 8mm(x2)
 140 QQT0380-001 POWER TRANSF T 1
141 QYSDSTL4008E TAP SCREW M4 x 8mm(x4)
142 QYSBSG3008E TAPP NG SCREW 3mm x 8mm
143 QYSDSG3008E TAPP NG SCREW 3mm x 8mm
144 LV10728-015A REAR PANEL
DP20
VBKC
144 LV10728-009A REAR PANEL
DP20
VBKJ
 Symbol No. Part No. Part Name Description Local
