JVC RX-DP20VBK Service Manual

3-5
145 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x8)
146 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x4)
147 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x6)
148 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
149 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x4)
150 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x4)
151 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x5)
152 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x6)
153 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x5)
154 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
155 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x4)
156 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
157 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x5)
158 QNC0095-001 AC INLET(2PIN)
159 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
160 LV40911-001A LABEL
161 E409257-001 GND TERM NAL
162 LV43356-001A KNOB
163 LV10538-006A TOP COVER
164 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x3)
165 E406308-003 SPECIAL SCREW (x8)
166 LV30226-029A SPACER
168 LV32819-002A VOL KNOB
169 LV33243-001A PROTECT SHEET
170 E71862-003T VOL.NUT
172 QUQ412-2119DJ FFC WIRE
173 QUQ412-2419DJ FFC WIRE
174 QUQ412-1522DJ FFC WIRE
175 QUQ412-1605DJ FFC WIRE
176 LV30225-074A SPACER
177 LV33163-001A BARRIER (x2)
178 QYSBSGG3008E TAPPING SCREW 3mm x 8mm(x3)
179 QQR0594-001 NOISE FILTER FL 1
180 QQR1406-001 NOISE FILTER FL 2
181 QNZ0649-001 EARTH TERMINAL (x2)
 182 QMF51U1-8R0-J1 FUSE
F 21 8A
AC125V
 183 QMF51N2-R50-J1 FUSE
F 41 0.5A
AC250V
 184 QMF51U1-2R0-J1 FUSE
F 43 2A
AC125V
 185 QMF51U1-2R0-J1 FUSE
F 42 2A
AC125V
186 LV42388-001A FUSE CAUTION (x3)
187 E67199-001 J=FISE C.LABEL
DP20
VBKJ
188 E75803-001 J=FUSE C.LABEL
DP20
VBKJ
189 E409396-003 CAUTION LABEL
DP20
VBKC
189 E409394-001 CAUTION LABEL
DP20
VBKJ
190 LV43341-006A LICENSE LABEL
DP20
VBKC
190 LV43341-005A LICENSE LABEL
DP20
VBKJ
191 QAM0486-001 SHORT PI PLUG (x2)
192 QYSBSG3008E TAPPING SCREW 3mm x 8mm(x6)
193 QYSBSG3008E TAPPING SCREW 3mm x 8mm(x5)
 194 KTA1046/Y/ TRANSISTOR Q 51 Q 52(x2)
195 LV32827-002A LED HOLDER (x3)
196 QUQ110-2105BJ FFC WIRE
197 VND4113-001 G.CAUTION
198 QWTJ809-210 GLASS TUBE
201 NNZ0095-001X EARTH TERMINAL
BC601 BC602
BC603 BC604
BC605 BC606(x6)
202 NNZ0095-001X EARTH TERMINAL BC 801 BC 802(x2)
203 E65507-001 CAUTION LABEL
DP20
VBKC
 Symbol No. Part No. Part Name Description Local
