Connections
4 PREPARATIONS
Connection to a high vision camera.
LINE 2
VIDEO
INPUT
AC
OUTPUT
MAX
100W
AC
INTPUT
120V
60Hz
AUDIO IN
HD/S3(W-VHS) HD(CAM/W-VHS) (HDTV/W-VHS) HD(HDTV/W-VHS) RGB(DISPLAY)
HD VIDEO IN HD VIDEO OUT1 HD VIDEO OUT2AUDIO OUT3
OUTPUT
SR
RL RLYP
B PR YPB PR
L
VIDEO
R.A. EDIT
PREROLL
S
REMOTE
RL
LINE 3
LINE 1 LINE 1
LINE 2
()
To
AUDIO
OUT 3
connector
To HD
VIDEO
IN
connector
To HD Video
output
connector
To AUDIO
output
connector
To AUDIO
Input
connector
To HD Video
Input
connector
To AUDIO
IN(HD/S3)
connector
To HD VIDEO
OUT 1
connector
High vision camera
High vision TV
