ENGLISH
395
418
407
68
286
3
3
336.3*
288
ø20
256*
334
175
1.5
POWER
CHROMA MENU
INPUT SELECT
PHASE
TM-A170
BRIGHT
CONTRAST VOLUME/SELECT
AB
Dimensions
< Front View >
< Side View >
* Asterisks (*) are used to indicate front panel
dimensions.
Unit : mm
Pin No. Signal
1 GND (Y)
2 GND (C)
3Y
4C
Y/C (Mini DIN 4 pin) terminal
specification
IN
Y/C
OUT
2
1
2
1
4
3
4
3
17
LCT1422-001A-H 07.10.25, 9:59 AM17
