3.2.4 SERVICE MENU SETTING ITEMS (SERVICE MODE)
SIGNAL BLOCK
WHITE BALANCE BLOCK
DEFLECTION BLOCK
CONTROL BLOCK (Don't change the values, because all fixed)
3.2.5 LANDING MENU SETTING ITEMS
Item Contents
S01 BRIGHT
S02 CONTRAST
S03 CHROMA(PAL)
S04 CHROMA(NTSC)
S05 PHASE(NTSC)
S06 CHROMA
S07 BRIGHT
S08 CONTRAST
S09 BRIGHT
S10 CONTRAST
S11 PHASE(PAL)
S12 PHASE
S13 CONT TRACKING
Item Contents
W01 R CUTOFF
W02 G CUTOFF
W03 B CUTOFF
W04 R DRIVE (6500K)
W05 B DRIVE (6500K)
W06 R DRIVE (9300K)
W07 B DRIVE (9300K)
W08 R CUTOFF
W09 G CUTOFF
W10 B CUTOFF
W11 R DRIVE (6500K)
W12 B DRIVE (6500K)
W13 R DRIVE (9300K)
W14 B DRIVE (9300K)
W15 R CUTOFF
W16 G CUTOFF
W17 B CUTOFF
W18 R DRIVE (6500K)
W19 B DRIVE (6500K)
W20 R DRIVE (9300K)
W21 B DRIVE (9300K)
W22 R CUTOFF
W23 G CUTOFF
W24 B CUTOFF
Item
Aspect ratio
Scan size
Vertical
frequency
Contents
D01
4:3
NORMAL
SCAN
50Hz
HORIZONTAL POSITION
D02 HORIZONTAL SIZE
D03 VERTICAL POSITION
D04 VERTICAL SIZE
D05 VERTICAL LINEARITY
D06 VERTICAL S-CORRECTION
D07 SIDEPIN PARABOLA
D08 SIDEPIN CORNER
There are many mode of the DEFLECTION BLOCK except for above
DA1~DA8 (4:3 / 60Hz)
DB1~DB8 (16:9 / 50Hz)
DC1~DC8 (16:9 / 60Hz)
DD1~DD8 (UNDER SCAN / 50Hz)
DE1~DE8 (UNDER SCAN / 60Hz)
DF7~DF8 (16:9 UNDER SCAN / 50Hz)
Item Contents
C01 DESTINATION
C02 BRIGHT POINT UPPER
C03 LOWER
C04 CONTRAST POINT UPPER
C05 LOWER
C06 CHROMA POINT UPPER
C07 LOWER
C08 PHASE POINT UPPER
C09 LOWER
C10 OSD HORIZONTAL POSITION
C11 OSD VERTICAL FREQUENCY 50Hz
C12 OSD VERTICAL FREQUENCY 60Hz
C13 HORIZONTAL CENTER (RGB)
C14 HORIZONTAL CENTER (COMPONENT)
C15 BRIGHT SERVICE
C16 SHARPNESS CENTER
C17 HVT H
C18 HVT V
C19 HVT H (UNDER SCAN)
C20 HVT V (UNDER SCAN)
C21 V-S.CORRECTION
C22 TRAPEZOID
C23 HOUR METER
C24 RUSH DELAY
C25 DEGAUSS DELAY TIME
C26~C33 SLOT IDENTIFY
C34 LANDING ENABLE
C35 LANDING START
Item Input signal Contents
- - - PAL / NTSC LANDING
