JVC TM-H150CG/E User Manual

(No.YA068)3-9
SIGNAL P.W. BOARD ASS'Y (FX-6143A-H2)
R4801 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R4802 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R4803 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R4804 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R4805 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R4806 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R4807 QRE141J-562Y C RESISTOR 5.6k Ω 1/4W J
R4808 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
R4809 QRE141J-332Y C RESISTOR 3.3k Ω 1/4W J
CN400A CHC101N-19S-L FFC CONNECTOR
S4801 QSW0619-003Z TACT SWITCH POWER
S4802 QSW0619-003Z TACT SWITCH INPUT_D
S4803 QSW0619-003Z TACT SWITCH INPUT_C
S4804 QSW0619-003Z TACT SWITCH INPUT_B
S4805 QSW0619-003Z TACT SWITCH INPUT_A
S4806 QSW0619-003Z TACT SWITCH ASPECT
S4807 QSW0619-003Z TACT SWITCH BLUE CHECK
S4808 QSW0619-003Z TACT SWITCH COLOR OFF
S4809 QSW0619-003Z TACT SWITCH UNDER SCAN
S4810 QSW0619-003Z TACT SWITCH MENU
S4811 QSW0619-003Z TACT SWITCH UP
S4812 QSW0619-003Z TACT SWITCH DOWN
S4813 QSW0619-003Z TACT SWITCH CONT/BRIGHT
S4814 QSW0619-003Z TACT SWITCH CHROMA/PHASE
 Ref No. Part No. Part Name Description Local
IC6001 JLC1562BF-X IC
IC6002 MM1311BD IC
IC6003 BA10358 IC
IC6004 LA6515 IC
IC6101 TC90A49AP IC
IC6102 NJM2234M-XE IC
IC6201 TA8772AN I.C(MONO-ANA)
IC6501 TA1276AN IC
IC6601 CD4053BNS-X IC
IC6602 CD4053BNS-X IC
IC6701 M37207MC-322SP IC(MCU)
IC6702 AT-24C08-H150CGE IC (SERVICE)
IC6703 L78LR05E-MA IC
IC6801 TC4538BF/N/-XE IC
IC6802 TC4538BF/N/-XE IC
IC6803 TC4538BF/N/-XE IC
IC6901 BA17809T IC
IC6903 BA17805T IC
IC6904 AN78L05-T IC
Q6001 2SC3928A/QR/-X TRANSISTOR
Q6002 2SC3928A/QR/-X TRANSISTOR
Q6003 2SC3928A/QR/-X TRANSISTOR
Q6101 2SC3928A/QR/-X TRANSISTOR
Q6102 2SC3928A/QR/-X TRANSISTOR
Q6103 2SC3928A/QR/-X TRANSISTOR
Q6104 2SC3928A/QR/-X TRANSISTOR
Q6105 2SC3928A/QR/-X TRANSISTOR
Q6106 2SC3928A/QR/-X TRANSISTOR
Q6107 2SC3928A/QR/-X TRANSISTOR
Q6108 DTC124EKA-X DIGI TRANSISTOR
Q6109 2SC3928A/QR/-X TRANSISTOR
Q6110 2SA1530A/QR/-X TRANSISTOR
Q6111 2SC3928A/QR/-X TRANSISTOR
Q6201 2SC3928A/QR/-X TRANSISTOR
Q6202 2SC3928A/QR/-X TRANSISTOR
Q6203 2SC3928A/QR/-X TRANSISTOR
Q6204 2SC3928A/QR/-X TRANSISTOR
Q6205 2SC3928A/QR/-X TRANSISTOR
Q6206 2SC3928A/QR/-X TRANSISTOR
Q6207 2SC3928A/QR/-X TRANSISTOR
Q6208 2SC3928A/QR/-X TRANSISTOR
Q6211 2SC3928A/QR/-X TRANSISTOR
Q6216 2SC3928A/QR/-X TRANSISTOR
Q6217 2SC3928A/QR/-X TRANSISTOR
Q6401 2SC3928A/QR/-X TRANSISTOR
Q6402 2SA965/OY/-T TRANSISTOR
Q6501 DTC124EKA-X DIGI TRANSISTOR
Q6502 2SC3928A/QR/-X TRANSISTOR
Q6503 2SA1530A/QR/-X TRANSISTOR
Q6504 2SA1530A/QR/-X TRANSISTOR
Q6505 2SA1530A/QR/-X TRANSISTOR
Q6507 2SA1530A/QR/-X TRANSISTOR
Q6508 DTC124EKA-X DIGI TRANSISTOR
 Ref No. Part No. Part Name Description Local
Q6509 2SC3928A/QR/-X TRANSISTOR
Q6510 DTC124EKA-X DIGI TRANSISTOR
Q6511 2SC3928A/QR/-X TRANSISTOR
Q6512 DTC124EKA-X DIGI TRANSISTOR
Q6513 DTC124EKA-X DIGI TRANSISTOR
Q6514 DTC124EKA-X DIGI TRANSISTOR
Q6515 2SC3928A/QR/-X TRANSISTOR
Q6516 2SC3928A/QR/-X TRANSISTOR
Q6601 2SC3928A/QR/-X TRANSISTOR
Q6603 2SC3928A/QR/-X TRANSISTOR
Q6605 2SC3928A/QR/-X TRANSISTOR
Q6607 2SC3928A/QR/-X TRANSISTOR
Q6609 2SC3928A/QR/-X TRANSISTOR
Q6611 2SC3928A/QR/-X TRANSISTOR
Q6612 DTC124EKA-X DIGI TRANSISTOR
Q6701 DTA124EKA-X DIGI TRANSISTOR
Q6702 DTA124EKA-X DIGI TRANSISTOR
Q6703 DTA124EKA-X DIGI TRANSISTOR
Q6704 DTA124EKA-X DIGI TRANSISTOR
Q6705 DTA124EKA-X DIGI TRANSISTOR
Q6706 DTA124EKA-X DIGI TRANSISTOR
Q6707 DTA124EKA-X DIGI TRANSISTOR
Q6708 DTA124EKA-X DIGI TRANSISTOR
Q6710 DTA124EKA-X DIGI TRANSISTOR
Q6711 DTA124EKA-X DIGI TRANSISTOR
Q6713 DTC124EKA-X DIGI TRANSISTOR
Q6715 DTC124EKA-X DIGI TRANSISTOR
Q6716 2SC3928A/QR/-X TRANSISTOR
Q6717 2SC3928A/QR/-X TRANSISTOR
Q6718 2SC3928A/QR/-X TRANSISTOR
Q6719 DTC124EKA-X DIGI TRANSISTOR
Q6720 2SC3928A/QR/-X TRANSISTOR
Q6801 2SC3928A/QR/-X TRANSISTOR
Q6802 2SC3928A/QR/-X TRANSISTOR
Q6803 2SC3928A/QR/-X TRANSISTOR
Q6804 2SA1530A/QR/-X TRANSISTOR
Q6805 2SC3928A/QR/-X TRANSISTOR
Q6807 DTC124EKA-X DIGI TRANSISTOR
Q6808 2SC3928A/QR/-X TRANSISTOR
Q6809 2SC3928A/QR/-X TRANSISTOR
Q6811 2SC3928A/QR/-X TRANSISTOR
D6001 MA111-X SI DIODE
D6002 MA111-X SI DIODE
D6003 MA111-X SI DIODE
D6004 MA111-X SI DIODE
D6006 MA111-X SI DIODE
D6007 MA111-X SI DIODE
D6008 MA111-X SI DIODE
D6010 MA111-X SI DIODE
D6011 MA111-X SI DIODE
D6012 MA111-X SI DIODE
D6013 MA111-X SI DIODE
D6015 MA111-X SI DIODE
D6016 MA111-X SI DIODE
D6017 MA111-X SI DIODE
D6018 MA3091/M/-X Z DIODE
D6023 MA111-X SI DIODE
D6024 MA111-X SI DIODE
D6025 MA111-X SI DIODE
D6026 MA111-X SI DIODE
D6027 MA111-X SI DIODE
D6028 MA111-X SI DIODE
D6029 MA111-X SI DIODE
D6030 MA111-X SI DIODE
D6031 MA111-X SI DIODE
D6032 MA111-X SI DIODE
D6033 MA3091/M/-X Z DIODE
D6034 MA111-X SI DIODE
D6401 MA111-X SI DIODE
D6503 MA111-X SI DIODE
D6504 MA111-X SI DIODE
D6505 MA111-X SI DIODE
D6506 MA111-X SI DIODE
D6507 MA111-X SI DIODE
D6508 MA111-X SI DIODE
D6509 MA111-X SI DIODE
D6510 MA111-X SI DIODE
D6511 MA111-X SI DIODE
D6512 MA111-X SI DIODE
D6513 MA111-X SI DIODE
D6514 MA111-X SI DIODE
D6515 MA111-X SI DIODE
D6516 MA111-X SI DIODE
D6517 MA111-X SI DIODE
D6518 MA111-X SI DIODE
D6519 MA111-X SI DIODE
 Ref No. Part No. Part Name Description Local

JVC TM-H150CG/E Specifications

General

Screen Size	15 inches
Display Type	CRT
Resolution	600 TV lines
Aspect Ratio	4:3
Weight	14 kg
Input Signal	Composite, S-Video, RGB
Video Standard	NTSC/PAL
