JVC TM-H150CG/E

(No.YA068)3-13
SLOT P.W. BOARD ASS'Y (FX-8033A-H2)
R6812 NRVA02D-102X CMF RESISTOR 1k Ω 1/10W D
R6814 NRVA02D-682X CMF RESISTOR 6.8k Ω 1/10W D
R6815 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R6816 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6820 NRVA02D-102X CMF RESISTOR 1k Ω 1/10W D
R6822 NRVA02D-472X CMF RESISTOR 4.7k Ω 1/10W D
R6824 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R6826 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R6827 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R6828 NRVA02D-152X CMF RESISTOR 1.5k Ω 1/10W D
R6830 NRVA02D-152X CMF RESISTOR 1.5k Ω 1/10W D
R6833 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6835 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R6836 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R6837 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R6842 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
L6101 QQL244K-100Z PEAKING COIL 10uH K
L6102 QQL244K-100Z PEAKING COIL 10uH K
L6103 QQL244K-100Z PEAKING COIL 10uH K
L6104 QQL244K-100Z PEAKING COIL 10uH K
L6106 QQL244K-330Z PEAKING COIL 33uH K
L6701 QQL244K-4R7Z PEAKING COIL 4.7uH K
L6702 QQL244K-8R2Z PEAKING COIL 8.2uH K
CN6001 QGB1505K1-25 CONNECTOR B-B (1-25)
CN6002 QGB1505K1-25 CONNECTOR B-B (1-25)
CN6005 QGB1505J1-25 CONNECTOR B-B (1-25)
CN600R QGA2501F1-03 CONNECTOR W-B (1-3)
CN600T QJB003-102810 SIN ID C-B WIRE
CN60S3 QGA2501F1-03 CONNECTOR W-B (1-3)
 CP6901 ICP-N10-Y IC PROTECTOR 400mA
 CP6903 ICP-N10-Y IC PROTECTOR 400mA
FL6101 CE42697-001 L P F
FL6102 CE42697-001 L P F
FL6201 CE42697-001 L P F
J6001 QNZ0561-001 D CONNECTOR REMOTE
J6002 CEMB021-002 BNC CONNECTOR VIDEO-A IN/OUT
J6003 CEMB021-002 BNC CONNECTOR VIDEO-B IN/OUT
J6004 QMD2B04-001 MINI CONNECTOR Y/C IN
J6005 QMD2B04-001 MINI CONNECTOR Y/C OUT
J6006 CEMN036-005 PIN JACK AUDIO IN/OUT
K6002 CE42681-001Y CHIP BEADS CORE
K6003 NQR0357-002X FERRITE BEADS
K6101 CE42681-001Y CHIP BEADS CORE
K6103 NQR0357-002X FERRITE BEADS
K6201 CE42681-001Y CHIP BEADS CORE
K6202 CE42681-001Y CHIP BEADS CORE
X6201 CE40749-001Z CRYSTAL
X6202 CE40668-001Z CRYSTAL
X6503 CSB503F30-T2 C RESONATOR
X6701 QAX0667-001Z C RESONATOR 8.000MHz
 Ref No. Part No. Part Name Description Local
IC8001 TC74VHC86F-X IC
IC8002 NJM2234M-XE IC
Q8001 2SC3928A/QR/-X TRANSISTOR
Q8002 2SA1530A/QR/-X TRANSISTOR
Q8003 2SA1530A/QR/-X TRANSISTOR
Q8004 2SC3928A/QR/-X TRANSISTOR
Q8005 2SC3928A/QR/-X TRANSISTOR
Q8006 2SC3928A/QR/-X TRANSISTOR
Q8007 2SC3928A/QR/-X TRANSISTOR
Q8008 2SC3928A/QR/-X TRANSISTOR
Q8009 2SC3837K/NP/-X TRANSISTOR
D8001 MA111-X SI DIODE
D8004 MA111-X SI DIODE
D8005 MA111-X SI DIODE
C8001 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C8002 QTNC1HM-105Z E CAPACITOR 1uF 50V M
C8004 QEHR1HM-335Z E CAPACITOR 3.3uF 50V M
C8005 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C8006 QTNC1HM-106Z E CAPACITOR 10uF 50V M
C8007 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C8008 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C8011 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C8012 NCB21CK-224X C CAPACITOR 0.22uF 16V K
C8013 QEHR1CM-107Z E CAPACITOR 100uF 16V M
 Ref No. Part No. Part Name Description Local
C8014 QEHR1CM-107Z E CAPACITOR 100uF 16V M
C8015 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C8016 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C8017 NDC31HJ-680X C CAPACITOR 68pF 50V J
C8018 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C8019 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C8020 NCB31HK-152X C CAPACITOR 1500pF 50V K
C8021 NDC31HJ-151X C CAPACITOR 150pF 50V J
R8001 NRSA63J-563X MG RESISTOR 56k Ω 1/16W J
R8002 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R8003 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R8004 NRSA63J-684X MG RESISTOR 680k Ω 1/16W J
R8005 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R8006 NRSA63J-181X MG RESISTOR 180 Ω 1/16W J
R8007 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R8008 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R8009 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R8010 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R8011 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R8012 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8013 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R8014 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R8015 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R8016 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R8017 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R8018 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R8019 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8020 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R8021 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R8022 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R8023 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R8024 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R8025 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R8026 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R8027 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R8028 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R8029 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R8030 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R8031 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8032 NRSA63J-683X MG RESISTOR 68k Ω 1/16W J
R8034 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R8035 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
CN8005 QGB1505K1-25 CONNECTOR B-B (1-25)
CN8006 QGB2514J1-50 CONNECTOR B-B (1-50)
