3-4(No.YA068)
EXPLODED VIEW PARTS LIST -2
Ref.No. Part No. Part Name Description Local
V01 M36AES13X01/L/ ITC
Inc.DEF YOKE/PC MAGNET/WEDGE
L01 QQW0186-001 DEG COIL
T1551 QQH0178-001 FB TRANSF
4 LC31575-001B-H PUSH KNOB (x4)
5 QQW0185-001 CANCELLER COIL
6 WJY0027-001A BRAIDED ASSY
7 CHFD119-14BD FFC WIRE
8 CEBSS08P-01KJ2 SPEAKER
9 LC11756-001A-H CHASSIS BASE
10 LC31577-001A-H FBT HOLDER
11 LC11764-002A-H TOP COVER
12 LC41453-001A ASSY SCREW (x13)
13 CM44287-00E ASSY SCREW (x3)
14 QNB0036-001 HEX SCREW (x2)
15 QSW0699-001 SEESAW SWITCH MAIN POWER
16 QMCB004-001 AC INLET
17 QYSBSF3010M TAP SCREW 3mm x 10mm(x5)
18 LC11763-001B-H REAR PANEL
19 QYSBSF4012Z TAP SCREW 4mm x 12mm(x3)
20 LC21283-001A-0L ROLL R LABEL
21 LC30475-003A-H WARNING LABEL
22 LC31464-003A-C SLOT PANEL
23 CM47686-00A FOOT (x4)
24 LC11762-001A-H BOTTOM COVER
25 QQR0491-001 CORE FILTER (GRAY)
26 QQR0803-001 CORE FILTER
30 FX-3075A-H2 CRT SOCKET PWB
31 FX-4092A-H2 FRONT CONTROL PWB
32 FX-1187A-H2 MAIN PWB
33 FX-2095A-H2 SUB DEF PWB
34 FX-6143A-H2 SIGNAL PWB
35 FX-8033A-H2 SLOT PWB
