JVC TM-H150CG/E User Manual

1-2 (No.YA068)
SPECIFICATION
Design & specifications are subject to change without notice.
Item Content
Dimensions (W × H × D) 36cm×31cm 41.8cm (14-1/4" ×12-1/4" ×16-1/2")
Mass 16kg (35.2lbs)
Color System PAL / NTSC 3.58
Scanning Frequency H: 15.734 kHz (NTSC), 15.625 kHz (PAL)
V: 59.94 Hz (NTSC), 50Hz (PAL)
Power Requirements AC 220V-240V, 50Hz/60Hz [TM-H150CG/E]
AC 120V, 50Hz/60Hz [TM-H150CG/U]
High Voltage 23.7kV~26.3kV [at zero beam current]
Power Consumption 0.8A [TM-H150CG/E]
1.2A [TM-H150CG/U]
Operation Temperature 5°C ~40°C (41°F ~104°F)
Operation Humidity 20%~80% (non-condensing)
Horizontal Resolution 750TV line or more
Picture Tube 15inch square type, in-line gun, trio-dot type, dot pitch 0.27mm
Effective Screen Size 35.6cm (Diagonal) / 28.55cm×21.4cm (W×H)
(14" / 11-3/16" ×8-3/8" )
High Voltage 23.7kV~26.3kV [at zero beam current]
Audio Power Output 1W (Monaural)
Speaker 8cm round × 1, 8Ω
Input / Output
Terminals
VIDEO A Composite video : 1V(p-p), 75Ω, negative sync, BNC connector×2
[Bridge connection possible with automatic termination]
VIDEO B Composite video : 1V(p-p), 75Ω, negative sync, BNC connector×2
[Bridge connection possible with automatic termination]
Y/C:Mini-Din 4-pin connector × 2
[Bridge connection possible with automatic termination]
Y:1V(p-p), 75 Ω
C:[NTSC] burst 0.286V(p-p), 75 Ω
[PAL] burst 0.3V(p-p), 75 Ω
AUDIO A 500mV(rms), high impedance, RCA pin jack×2
[Bridge connection possible]
AUDIO B 500mV(rms), high impedance, RCA pin jack×2
[Bridge connection possible]
Remote Control Input D-sub 15pin (3row) connector×1
[MAKE or TRIGGER can be switched in MENU]
Card Slot (option) COMPONENT / RGB input card (IF-C01COMG available)
SDI input card (IF-C01SDG, IF-C21SDG, IF-C51SDG available)
