JVC XV-SA600BK Service Manual

XV-SA600BK/XV-SA602SL
3-13
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 02
A
BK 1 LE20539-001A FL HOLDER
C 1 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 2 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 3 NCB21CK-105X C CAPACITOR
C 4 QEKC1AM-476Z E CAPACITOR
47MF 20% 10V
C 5 QETN0JM-227Z E CAPACITOR
220MF 20% 6.3V
C 6 NCB31CK-104X C CAPACITOR
C 7 NCB31CK-103X C CAPACITOR
C 8 NCB31CK-104X C CAPACITOR
C 9 NCS31HJ-331X C.CAPA. C.M
C 10 NCB21CK-105X C CAPACITOR
C 11 NCB21CK-105X C CAPACITOR
C 12 NCB21CK-105X C CAPACITOR
C 700 QTE0J28-227Z E CAPACITOR
C 701 NCB31HK-152X C CAPACITOR
C 704 NCS31HJ-101X C.CAPA. C.M
C 707 QETN1AM-107Z E CAPACITOR
100MF 20% 10V
C 711 QCZ0202-155Z ML C CAPA I/M
1.5MF
C 713 NCS31HJ-101X C.CAPA. C.M
C 714 QTE0J28-477Z E CAPACITOR
C 716 QTE0J28-477Z E CAPACITOR
C 717 QCZ0202-155Z ML C CAPA I/M 1.5MF
C 724 NCB31HK-102X C CAPACITOR
C 730 QFV21HJ-224Z MF CAPACITOR
.22MF 5% 50V
C 731 QFN31HJ-103Z M CAPACITOR
.010MF 5% 50V
C 735 NCB31CK-104X C CAPACITOR
C 740 QFLC1HJ-561Z M CAPACITOR
560PF 5% 50V
C 741 QFP31HJ-121Z PP CAPACITOR
120PF 5% 50V
C 742 QFLC1HJ-182Z M CAPACITOR
1800PF 5% 50V
C 743 QFN31HJ-272Z M CAPACITOR 2700PF 5% 50V
C 744 QFLC1HJ-561Z M CAPACITOR 560PF 5% 50V
C 745 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C 746 QTE1A48-476Z E.CAPA I/M
C 747 QFLC1HJ-182Z M CAPACITOR
1800PF 5% 50V
C 748 QFLC1HJ-561Z M CAPACITOR
560PF 5% 50V
C 749 QFLC1HJ-561Z M CAPACITOR
560PF 5% 50V
C 750 QFLC1HJ-561Z M CAPACITOR
560PF 5% 50V
C 751 QFP31HJ-121Z PP CAPACITOR
120PF 5% 50V
C 752 QFLC1HJ-182Z M CAPACITOR 1800PF 5% 50V
C 753 QFN31HJ-272Z M CAPACITOR 2700PF 5% 50V
C 754 QFLC1HJ-561Z M CAPACITOR 560PF 5% 50V
C 755 QFLC1HJ-103Z M CAPACITOR .010MF 5% 50V
C 756 QTE1A48-476Z E.CAPA I/M
C 757 QFLC1HJ-182Z M CAPACITOR
1800PF 5% 50V
C 761 QTE1C28-107Z E CAPACITOR
C 762 QTE1C28-107Z E CAPACITOR
C 771 QTE1C28-107Z E CAPACITOR
C 772 QTE1C28-107Z E CAPACITOR
C 797 NCB31HK-152X C CAPACITOR
C 801 QEZ0592-107Z E CAPACITOR 100MF
C 802 NCB31CK-104X C CAPACITOR
C 803 NCB31CK-104X C CAPACITOR
C 806 QEZ0592-107Z E CAPACITOR
100MF
C 808 QEZ0592-107Z E CAPACITOR
100MF
C 810 QEZ0592-107Z E CAPACITOR
100MF
C 811 NCB31CK-104X C CAPACITOR
C 812 QEZ0598-226Z E CAPACITOR
22MF
C 813 QETN1AM-477Z E CAPACITOR 470MF 20% 10V
C 814 QEZ0598-226Z E CAPACITOR 22MF
C 815 QETN1AM-477Z E CAPACITOR 470MF 20% 10V
C 817 QEKC1EM-226Z E CAPACITOR 22MF 20% 25V
C 819 QEZ0598-226Z E CAPACITOR
22MF
C 833 NCB31HK-103X C CAPACITOR
C 834 NCB31CK-104X C CAPACITOR
C 835 NCB21CK-105X C CAPACITOR
C 836 NCB31CK-103X C CAPACITOR
C 837 NCS31HJ-101X C.CAPA. C.M
C 838 NCS31HJ-101X C.CAPA. C.M
C 839 NCS31HJ-101X C.CAPA. C.M
C 840 NCS31HJ-101X C.CAPA. C.M
C 902 QFZ9075-683 M CAPACITOR
A
.068MF
C 903 QFZ9075-683 M CAPACITOR
A
.068MF
C 905 QCZ9079-102 C CAPACITOR
A
1000PF
C 906 QCZ9079-102 C CAPACITOR
A
1000PF
C 907 QETM2DM-157 E CAPACITOR
A
J/C/DOM
C 908 QCZ0136-332Z C CAPACITOR 3300PF
C 913 QCZ0136-101Z C CAPACITOR 100PF
C 914 QEZ0532-396Z E CAPACITOR 39MF
C 915 NCB31HK-471X C CAPACITOR
C 917 NCB31CK-104X C CAPACITOR
C 921 NCS31HJ-101X C.CAPA. C.M
C 922 NCS31HJ-101X C.CAPA. C.M
C 923 NCS31HJ-101X C.CAPA. C.M
C 924 NCS31HJ-101X C.CAPA. C.M
C 926 NCS31HJ-101X C.CAPA. C.M
C 927 NCS31HJ-101X C.CAPA. C.M
C 928 NCS31HJ-101X C.CAPA. C.M
C 960 QEZ0529-826Z E CAPACITOR 82MF
C 961 NCB31CK-104X C CAPACITOR
C 962 QETN1HM-226Z E CAPACITOR
22MF 20% 50V
C 963 QEZ0533-396Z E CAPACITOR
39MF
C 964 NCB31CK-104X C CAPACITOR
C 965 QEZ0586-567 E CAPACITOR
560MF
C 966 QETN1AM-477Z E CAPACITOR
470MF 20% 10V
C 968 NCB21CK-105X C CAPACITOR
C 969 QETN0JM-227Z E CAPACITOR 220MF 20% 6.3V
C 971 QETN1HM-107Z E CAPACITOR 100MF 20% 50V
C 972 NCS31HJ-471X C CAPACITOR
C 975 QEZ0591-108 E CAPACITOR 1000MF
C 976 QETN0JM-477Z E CAPACITOR
470MF 20% 6.3V
C 978 QETN1AM-107Z E CAPACITOR
100MF 20% 10V
C 979 QEZ0530-827 E CAPACITOR
820MF
C 981 NCB31CK-104X C CAPACITOR
C 982 QEZ0594-187Z E CAPACITOR
180MF
C 984 QETN1CM-227Z E CAPACITOR 220MF 20% 16V
C 986 NCB21CK-334X C.CAPA. C.M
C 987 QEZ0594-187Z E CAPACITOR 180MF
C 989 QETN1CM-227Z E CAPACITOR 220MF 20% 16V
C 990 NCB21CK-334X C.CAPA. C.M
C 991 QETN0JM-227Z E CAPACITOR
220MF 20% 6.3V
C 992 QETN0JM-227Z E CAPACITOR
220MF 20% 6.3V
C 993 NCS31HJ-101X C.CAPA. C.M
C 994 QETN1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 995 NCB21CK-105X C CAPACITOR
C 997 QETN1CM-227Z E CAPACITOR 220MF 20% 16V
C1701 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C1702 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1703 NCS31HJ-151X C CAPACITOR
C1704 NCS31HJ-331X C.CAPA. C.M
C1706 NCB31CK-104X C CAPACITOR
CN 4 QGD2501C1-04Z SOCKET
CN512 QGB2027M8-26 CONNECTOR
CN513 QGB2027M8-26 CONNECTOR
CN701 QGF1205C1-17 CONNECTOR
CP951 ICP-N10-T ICP
A
CP952 ICP-N5-T ICP
D 1 SPR-325MVW/L/-T LED STANDBY
D 2 SPR-325MVW/L/-T LED
PROGRESSIVE
D 3 SELU2E10C LED
D 9 1SS355-X DIODE C.M
D 901 S1WB/A/60-4101 BRIDGE DIODE
A
D 903 SARS01-T2 FR DIODE
A
Item
Parts number Parts name Area
Remarks
A
