JVC XV-SA600BK Service Manual

XV-SA600BK/XV-SA602SL
3-14
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 02
A
D 904 F1T4-T2 FR DIODE
A
D 905 F1T4-T2 FR DIODE
D 908 F1T4-T2 FR DIODE
A
D 951 F1T4-T2 FR DIODE
A
D 952 F1T4-T2 FR DIODE
A
D 954 F1T4-T2 FR DIODE
A
D 956 F1T4-T2 FR DIODE
A
D 957 F1T4-T2 FR DIODE
A
D 960 MTZJ4.7B-T2 Z DIODE I M
D 981 RK34-LFB2 SB DIODE
A
A
D 991 HZS3CLL-T2 Z DIODE
D 998 F1T4-T2 FR DIODE
DI 1 QLF0103-002 FL TUBE
EP711 QNZ0136-001Z EARTH PLATE
EP901 QNZ0136-001Z EARTH PLATE
EP951 QNZ0136-001Z EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
FW 1 QUM104-12DGZ4 PARA RIBON WIRE
FW 2 QUM108-15DGZ4 PARA RIBON WIRE
IC 1 GP1UD271XK RM RECIVER
IC 2 MN101C35DLJ IC SYSTEM MICOM
IC 3 XC61FN2712M-X IC
IC703 MN35505-X IC C M
IC704 TC74HC08AF-X IC
IC741 NJM5532M-XE IC
IC751 NJM5532M-XE IC
IC801 MM1568CJ-X IC
IC901 STR-G6551R-F8 IC(HYBRID)
IC951 MM1565AF-X IC
IC952 PQ3RD23 IC
J 700 QNN0461-001 PIN JACK AUDIO L/R
J 701 QNN0458-001 PIN JACK COAXIAL
J 702 QNS0089-001 3.5 JACK
AV COMPULINK
J 703 GP1FA351TZ OPT TRANSMITTER
OPT DIGITAL OUT
J 801 QNN0395-001 PIN JACK
COMPONENT
J 802 QNN0454-001 PIN JACK
S/COMP.
JT102 QGD2501C1-05Z SOCKET I.M
CN2
JT103 QGD2501C1-03Z SOCKET
K 101 NQR0227-004X FERRITE BEADS
K 701 NRSA63J-0R0X MG RESISTOR
K 703 NRSA63J-0R0X MG RESISTOR
K 704 NRSA63J-0R0X MG RESISTOR
K 705 NQR0227-004X FERRITE BEADS
K 706 NQR0227-004X FERRITE BEADS
K 711 QQR1183-001Z FERRITE BEADS
K 721 QQR1183-001Z FERRITE BEADS
K 801 QQR0601-001Z FERRITE BEADS
K 902 QQR1183-001Z FERRITE BEADS
K1701 NQR0227-004X FERRITE BEADS
K1702 NQR0227-004X FERRITE BEADS
L 709 QQL231K-2R2Y INDUCTOR
L 901 QQR1105-001 LINE FILTER
A
L 952 QQR1291-001Z CHOKE COIL
L 955 QQR1291-001Z CHOKE COIL
L 957 QQL244K-100Z INDUCTOR
L 959 QQL244K-100Z INDUCTOR
L 960 QQR1291-001Z CHOKE COIL
L1701 QQL231K-R68Y INDUCTOR I.M
P 901 QNC0092-001 AC INLET J/C
PC901 PC123Y02 IC(PHOTO COUPLE
A
Q
1 KRC104S-X TRANSISTOR
Q
2 KRC107S-X DIGITAL.TR
Q
4 KRC109S-X TRANSISTOR
Q
5 KRA102S-X DIGITAL.TR
Q
13 KRC107S-X DIGITAL.TR
Q 14 KRA102S-X DIGITAL.TR
Q
15 KRC107S-X DIGITAL.TR
Q
16 KRA102S-X DIGITAL.TR
Q
17 KRC107S-X DIGITAL.TR
Q
18 KRA102S-X DIGITAL.TR
Q
19 KRC107S-X DIGITAL.TR
Q
20 KRA102S-X DIGITAL.TR
Q
25 KRA102S-X DIGITAL.TR
Q
743 2SC3576-JVC-T TRANSISTOR I/M
AMUTE1
Q 753 2SC3576-JVC-T TRANSISTOR I/M AMUTE1
Q 755 2SC3576-JVC-T TRANSISTOR I/M FRE
Q
Q
756 2SC3576-JVC-T TRANSISTOR I/M FRE
Q
Q
791 2SC2412K/RS/-X CHIP TRANSISTOR
Q
792 KRA102S-X DIGITAL.TR
Q
951 2SC3576-JVC-T TRANSISTOR I/M
Q
952 KRA104S-X DIGITAL.TR
Q
991 KTC3199/Y/-T TR I/M
R 2 NRSA63J-431X MG RESISTOR
R 3 NRSA63J-681X MG RESISTOR
R 4 NRSA63J-112X MG RESISTOR
R 5 NRSA63J-222X MG RESISTOR
R 6 NRSA63J-681X MG RESISTOR
R 7 NRSA63J-222X MG RESISTOR
R 8 NRSA63J-151X MG RESISTOR
R 10 NRSA63J-820X MG RESISTOR
R 11 NRSA63J-0R0X MG RESISTOR
R 12 NRSA63J-820X MG RESISTOR
R 13 NRSA63J-102X MG RESISTOR
R 14 NRSA63J-820X MG RESISTOR
R 16 NRSA63J-222X MG RESISTOR
R 18 NRSA63J-102X MG RESISTOR
R 19 NRSA63J-472X MG RESISTOR
R 21 NRSA63J-472X MG RESISTOR
R 23 NRSA63J-222X MG RESISTOR
R 31 NRSA63J-103X MG RESISTOR
R 32 NRSA63J-0R0X MG RESISTOR
R 33 NRSA63J-102X MG RESISTOR
R 36 NRSA63J-0R0X MG RESISTOR
R 38 NRSA63J-222X MG RESISTOR
R 39 NRSA63J-222X MG RESISTOR
R 45 NRSA63J-103X MG RESISTOR
R 46 NRSA63J-103X MG RESISTOR
R 56 NRSA63J-152X MG RESISTOR
R 700 NRSA63J-105X MG RESISTOR
R 701 NRSA63J-103X MG RESISTOR
R 702 NRSA63J-105X MG RESISTOR
R 703 NRSA63J-103X MG RESISTOR
R 706 NRSA63J-104X MG RESISTOR
R 708 NRSA63J-101X MG RESISTOR
R 711 QRE141J-100Y C RESISTOR 10 5% 1/4W
R 712 QRE141J-220Y C RESISTOR 22 5% 1/4W
R 713 QRE141J-470Y C RESISTOR 47 5% 1/4W
R 715 QRE141J-470Y C RESISTOR
47 5% 1/4W
R 721 NRSA63J-471X MG RESISTOR
R 723 NRSA63J-471X MG RESISTOR
R 724 NRSA63J-471X MG RESISTOR
R 725 NRSA63J-471X MG RESISTOR
R 726 QRE141J-330Y C RESISTOR 33 5% 1/4W
R 728 NRSA63J-471X MG RESISTOR
R 729 NRSA63J-471X MG RESISTOR
R 731 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R 740 QRE141J-273Y C RESISTOR
27K 5% 1/4W
R 741 QRE141J-273Y C RESISTOR
27K 5% 1/4W
R 742 QRA14CF-1802Y MF RESISTOR
18 1/4W
R 743 QRA14CF-1802Y MF RESISTOR
18 1/4W
R 744 NRSA63J-362X MG RESISTOR
