JVC XV-SA600BK Service Manual

XV-SA600BK/XV-SA602SL
3-15
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 02
A
A
A
A
R 746 QRA14CF-3301Y MF RESISTOR 33 1/4W
R 747 NRSA63J-362X MG RESISTOR
R 748 QRA14CF-6800Y MF RESISTOR 68 1/4W
R 750 QRE141J-273Y C RESISTOR 27K 5% 1/4W
R 751 QRE141J-273Y C RESISTOR
27K 5% 1/4W
R 752 QRA14CF-1802Y MF RESISTOR
18 1/4W
R 753 QRA14CF-1802Y MF RESISTOR
18 1/4W
R 754 NRSA63J-362X MG RESISTOR
R 756 QRA14CF-3301Y MF RESISTOR
33 1/4W
R 757 NRSA63J-362X MG RESISTOR
R 758 QRA14CF-6800Y MF RESISTOR 68 1/4W
R 761 QRA14CF-6200Y MF RESISTOR 62 1/4W
R 762 QRE141J-821Y C RESISTOR 820 5% 1/4W
R 763 NRSA63J-362X MG RESISTOR
R 764 QRE141J-183Y C RESISTOR
18K 5% 1/4W
R 765 QRE141J-561Y C RESISTOR
560 5% 1/4W
R 766 QRE141J-273Y C RESISTOR
27K 5% 1/4W
R 767 QRE141J-101Y C RESISTOR
100 5% 1/4W
R 768 NRSA63J-103X MG RESISTOR
R 771 QRA14CF-6200Y MF RESISTOR 62 1/4W
R 772 QRE141J-821Y C RESISTOR 820 5% 1/4W
R 773 NRSA63J-362X MG RESISTOR
R 774 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 775 QRE141J-561Y C RESISTOR
560 5% 1/4W
R 776 QRE141J-273Y C RESISTOR
27K 5% 1/4W
R 777 QRE141J-101Y C RESISTOR
100 5% 1/4W
R 778 NRSA63J-103X MG RESISTOR
R 782 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 783 QRE141J-221Y C RESISTOR
220 5% 1/4W
R 789 NRSA63J-103X MG RESISTOR
R 792 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 793 QRE141J-221Y C RESISTOR 220 5% 1/4W
R 794 NRSA63J-103X MG RESISTOR
R 795 NRSA63J-103X MG RESISTOR
R 796 NRSA63J-103X MG RESISTOR
R 797 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R 798 NRSA63J-473X MG RESISTOR
R 799 NRSA63J-333X MG RESISTOR
R 801 NRSA63J-750X MG RESISTOR
R 802 NRSA63J-750X MG RESISTOR
R 803 NRSA63J-750X MG RESISTOR
R 804 NRSA63J-750X MG RESISTOR
R 805 NRSA63J-750X MG RESISTOR
R 808 NRSA63J-750X MG RESISTOR
R 831 NRVA63D-750X RES. C.M
R 834 NRVA63D-750X RES. C.M
R 836 NRVA63D-680X RES. C.M
R 838 NRVA63D-680X RES. C.M
R 851 NRSA63J-223X MG RESISTOR
R 852 NRSA63J-223X MG RESISTOR
R 853 NRSA63J-0R0X MG RESISTOR COMP
R 856 NRSA63J-0R0X MG RESISTOR COMP
R 863 NRSA63J-102X MG RESISTOR
R 901 QRL01DJ-683X OMF RESISTOR
68K 5% 1/1W
R 903 QRE141J-270Y C RESISTOR
27 5% 1/4W
R 905 QRL027J-683 OMF RESISTOR
68K 5% 1/2W
R 906 QRE141J-681Y C RESISTOR
680 5% 1/4W
R 907 QRT022J-R47 OMF RESISTOR 5% 1/2W
R 908 QRE141J-332Y C RESISTOR 3.3K 5% 1/4
W
R 920 QRZ9037-335 F RESISTOR 3.3M 1/0W
R 921 QRL01DJ-470X OMF RESISTOR 47 5% 1/1W
R 952 NRSA63J-103X MG RESISTOR
R 953 NRSA63J-103X MG RESISTOR
R 955 NRSA63J-223X MG RESISTOR
R 956 QRE141J-180Y C RESISTOR
18 5% 1/4W
R 960 NRSA63J-390X MG RESISTOR
R 961 NRSA63J-681X MG RESISTOR
R 962 NRSA63J-151X MG RESISTOR
R 965 NRSA63J-104X MG RESISTOR
R 967 NRSA63J-472X MG RESISTOR
R 968 NRSA63J-390X MG RESISTOR
R 969 NRSA63J-271X MG RESISTOR
R 982 NRSA63J-0R0X MG RESISTOR
R 992 QRZ9005-100X F RESISTOR
10 1/0W
R1107 NRSA63J-431X MG RESISTOR
R1500 QRA14CF-1802Y MF RESISTOR 18 1/4W
R1501 QRA14CF-1802Y MF RESISTOR 18 1/4W
R1721 QRE141J-100Y C RESISTOR 10 5% 1/4W
R1722 NRSA63J-391X MG RESISTOR
R1724 NRSA63J-101X MG RESISTOR
R1725 NRSA63J-391X MG RESISTOR
R1727 NRSA63J-101X MG RESISTOR
R1728 NRSA63J-100X MG RESISTOR
R8341 NRVA63D-122X MG RESISTOR
S 1 QSW0651-001Z TACT SWITCH
S 2 QSW0651-001Z TACT SWITCH
S 3 QSW0651-001Z TACT SWITCH
S 4 QSW0651-001Z TACT SWITCH
S 5 QSW0651-001Z TACT SWITCH
S 6 QSW0651-001Z TACT SWITCH
S 7 QSW0651-001Z TACT SWITCH
S 802 QSW0986-001 SLIDE SWITCH
T 901 QQS0150-001 SW TRANSF
A
X 1 QAX0667-001Z RESONATOR I.M
Item
Parts number Parts name Area
Remarks
A
