Kaadas K8-T - Package Contents and Components; Explosive View Components

2 keys
2
Number Item name
Quantity
Lock body
Inside escutcheon
Outside escutcheon
1
2
3
4
5
6
7
8
9
10
11
Remark
1
1
1
User manual
1
1
1
1
1
Screw pack
Warranty card
1
Key box
1
Strike plate and dust cover
Installation template
Mounting plate
2
RFID Card
Package C ontent and E xplos ive V iew
This described package content is for reference only, the real products should be
considered as final. If some components lost, please check with the sellers.
1. Battery cover (1 pc)
2. M6 upper connecting mounting screw (1 pc)
3. Inside escutcheon assembly (1 pc)
4. Square shaft (2 pcs)
5. M5 mounting plate screw (4 pcs)
6. Mortise lock (1 pc)
7. Mounting screw (4 pcs)
8. M5 connecting screw bolt (4 pcs)
9. M6 upper connecting screw bolt (1 pc)
10. Pressure spring (1 pc)
11. Outside escutcheon assembly (1 pc)
12. Mounting plate (1 pc)
13. M6 bottom mounting screw (1 pc)
14. Bottom cover (1 pc)
