1 • CHECKLIST AND EXPLODED VIEWS
PK2915-T 07_2014 E-760/770/790 SERIES RETROFIT INSTALLATION GUIDE
Page 2
Each Generation E-760/770/790 retrofit kit for Unican System 700 locks includes:
(A) Outside lever handle for electronic override
(B) Outside housing for electronic override
(C) Battery holder with 3 AA batteries
(D) Inside trim assembly
(A1) Outside lever handle for key-in-knob mechanical override
(B1) Outside housing for key-in-knob mechanical override
Parts inside hardware bag:
(C1) Cylinder plug
(D1) Cylinder
(E) Thumbturn (hex) spindle
(E1) Cylinder Cap
(F) Compression spring
(G) Short square half-spindle (with slotted head)
(H) Long square half-spindle (with tapered end)
(I) Torx-head screw
(J) 3 x mounting screws (10-24, 1/8" hex head) or 12-24, 1/8" hex head for recent model only
(K) 1 extension spring
(L) Additional parts for Office or Storeroom function mortise
Parts available separately:
(M) Replacement strike and mounting screws
(N) Light duty drilling jig (part #138-51093)
— Paper drilling template
Tools Required
Safety glasses
1
/
8
" hex (Allen) key
1
/
16
" hex (Allen) key
3
/
32
" hex (Allen) key
Small flat screwdriver
Torx screwdriver (T-15)
Phillips screwdriver (#2)
1
/
2
" drill bit
Drill
Awl or center punch (if using paper template or mechanical override)
Clamp (if using metal jig)
Cleaning supplies
©
2014 Kaba Ilco, Inc. All trademarks and registered trademarks are the property of their respective owners.
For outdoor installations, order outdoor gasket 033-510181-1 for E-760. For 770/790 Series order gasket 033-512017-1
For doors more than 2
1
/
2
" (63.5mm) thick, order the appropriate hardware bag
to receive the correct length of spindles and mounting screws.
