Technical Data
Page  KACO Operating Instructions blueplanet . TL - . TL
 Technical Data
. Electrical data
Product name: KACO blueplanet 5.0 TL3 6.5 TL3 7.5 TL3
Input levels
Maximal empfohlene DC Leistung [kW] 6 7,8 9
MPP@Pnom from [V] to [V] 240 ... 800 310 ... 800 350 ... 800
Operating range from [V] to [V] 200 ... 950
Starting voltage [V]* 250
No-load voltage (U
OC max
) [V]
1 000 (start to 950)
Max. input current [A] 2 x 11
Max. power per MPP tracker [W]
5 200 6 700 7 700
Number of strings 2
Number of MPP controls 2
max. short-circuit current (I
SC max
) [A]
16 (per tracker)
max. input source feedback current 0
Output levels
Rated power [VA]
5 000 6 500 7 500
Grid voltage [V] 400/230 (3/N/PE)
Rated current [A]
3 x 7.25 3 x 9.50 3 x 10.90
Max. rated current [A]
3 x 7.62 3 x 9.98 3 x 11.45
contribution to maximum peak current (îp) [A] 35
Initial short-circuit alternating current (lk” rst
single period eective value) [A]
16.5
Start-up current [A] 1.03
Rated frequency [Hz] 50/60
cos phi 0.30 inductive ...0.30 capacitive
Number of feed-in phases 3
THD [%] 3.85
General electrical data
Eciency [%]
98.3 98.3 98.3
European eciency [%]
97.4 97.6 97.7
Self consumption: night [W] 2
Feed-in starts at [W] 20
Circuit design Transformerless
Grid monitoring Country-specic
Ground fault monitoring Yes
Table 1: Electrical data

Kaco blueplanet 3.0 TL3 Specifications

General

Brand	Kaco
Model	blueplanet 3.0 TL3
Category	Inverter
Language	English
