Technical Data
Page  KACO Operating Instructions blueplanet . TL - . TL
. Mechanical data
Product name: KACO blueplanet 5.0-10.0 TL3
Display Graphical LCD, 3 LEDs
Controls 4-way button, 2 buttons
Interfaces 2 x Ethernet, USB, RS485, error relay
4 x digital inputs (optional)
Fault signal relay Potential-free NO contact 30 V / 1A
AC connections 5-pole connection plug
DC connections 4 (2 x 2) SUNCLIX connector
Ethernet connection: Cable connection Cable connection via M25 cable tting
Ambient temperature range [°C] -25 ... +60, power derating from +40
Humidity range (non-condensing) [%] 100
Maximum installation elevation [m above sea level] 3000
Temperature monitoring Yes
Cooling (free convection (K)/fan (L)) L
Protection rating according to EN 60529 IP65
Degree of contamination 2
Noise emission [dB(A)] <53
DC isolator switch Built-in
Housing Plastic (ASA/PC), aluminium
H x W x D [mm] approx. 522 x 363 x 246
Total weight [kg] 30
CE conformity Yes
Table 3: Mechanical data
* The DC starting voltage can be set in the menu if needed.
. Identication
Identifying the unit
ඣ You will nd the name plate with product-specic data for service and
other requirements specic to installation on the right side panel of
the inverter. This data includes:
• Product name
• Part no.
• Serial no.
• Date of manufacture
• Technical Data
• Disposal information
• Certication marking, CE marking.
KACO new energy
Carl-Zeiss-Straße 1
74172 Neckarsulm
Made in Germany
KACO blueplanet 7.5 TL3 M2 WM OD IIG0
Part number 1001203
Serial number 00000000000010005
Year
Q2 / 16
Input
Vmax PV / lsc PV (max) / Inom PV 1000 Vdc /2x 16 A /2x 11 A
V-MPP at Pnom / V- range 350V-800V/200V-800V
Output
Nominal voltage
400V/230V(3/N/PE)
Voltage range continuous operation 3 x 180 Vac - 277 Vac
Current (maximum continuous)
3 x 11,45 A
Frequency range
45Hz-65Hz
Output
Power
Snom at 400 V /230 V Unom 7500 VA
Reactive power cos phi 0-95 % Snom 1 - 0,3 ind/cap
Environ-
ment
Temperature range
-25°C...+60°C/-13°F...+140°F
Protection class / Ingress protection I/IP65
ARC fault circuit protection non
Interface protection according to country
specific r equirements, details see manual
No galvanic separation
4004945
Figure : Name plate
