Katherm HK
Assembly, installation and operating instructions
12
4 Technical data
Unit Katherm HK (performance values for roll-up grille)
Size HK 245 HK 320 HK 320 E HK 290 HK 360
Trench width [mm] 245 320 320 290 360
Trench height [mm] 160 130 130 160 210
Trench length [mm] 915 - 3000 915 - 3000 915 - 3000 950 - 3000 950 - 2250
Air volume flow [m³/h] 56 - 1002 45 - 925 45 - 925 40 - 1295 95 - 1545
Heat output, 2-pipe
1
637 - 8710 971 - 10310 942 - 9716 1057 - 15715 1223 - 16884
Heat output, 4-pipe
1
462 - 6316 436 - 6512 ./. 514 - 9448 643 - 12243
Electric heat output
[W]
- - 100 - 1500 - -
Cooling output, 2-pipe
2
66 - 1507 108 - 1928 91 - 1854 114 - 2783 120 - 3348
Cooling output, 4-pipe
2
62 - 1420 105 - 1854 ./. 112 - 2728 114 - 3153
Sound pressure level
[dB (A)]
3,
4
<20 - 45 <20 - 41 <20 - 41 <20 - 45 <20 - 53
Sound power level
[dB(A)]
4
<28 - 53 <28 - 49 <28 - 49 <28 - 53 <28 - 61
Power consumption
[W]
4.7 - 33.3 4.7 - 33.3 4.7 - 33.3 4.2 - 52.9 2.3 - 54.0
Current consumption
[mA]
49 - 345 49 - 345 49 - 345 56 - 409 22 - 521
Water content [l] 0.31 - 2.01 0.50 - 3.10 0.44 - 2.76 0.53 - 2.84 0.50 - 3.10
Weight [kg] 16.57 - 56.76 17.63 - 60.39 17.63 - 60.39 21.21 - 74.38 25.08 - 59.39
1
at LPHW 75 / 65 °C, t
L1
= 20°C, with fan-assisted convection
2
at CHW 16/18 °C, t
L1
= 27 °C, 48% relative humidity with fan coils
3
The sound pressure level was calculated with an assumed room insulation of 8 dB(A). This corresponds to a dis-
tance of 2 m, a room volume of 100 m³ and a reverberation time of 0.5 s (in accordance with VDI 2081).
4
Sound pressure level < 20 dB (A) and sound power level < 28 dB (A) outside the usual measuring and audible
range.
