12 List of KaControl parameters
12.1 Katherm HK/ HK E parameter list
Parameter Function Standard Min. Max. Unit Katherm HK
9
Katherm HK
E
10
P000 Software version 24 0 255 - 24 24
P001 Base setpoint for setpoint input ± 3K 22 8 32 °C 22 22
P002 Switch-on and switch-off hysteresis for valves 3 0 255 K/10 1 1
P003
Neutral zone in a 4-pipe system (only in automatic
mode)
3 0 255 K/10 20 20
P004 Cooling without fan assistance (natural convection) 0 0 255 K/10 0 0
P005 Heating without fan assistance (natural convection) 5 0 255 K/10 0 0
P006 Fan On/Off hysteresis (only in ventilation mode) 5 0 255 K/10 5 5
P007 P-band, heating 20 0 100 K/10 25 25
P008 P-band, cooling 20 0 100 K/10 25 25
P009 Offset to the base setpoint for setpoint input ± 3K 3 0 10 C 3 3
P010
Contact sensor: limit value temperature to activate
fan stages 1 and 2 in heating mode
26 0 255 °C 26 26
P011
Contact sensor: limit value temperature to activate
fan stages 3 and 4 in heating mode
28 0 255 °C 28 28
P012
Contact sensor: limit value temperature to activate
fan stage 5 in heating mode
30 0 255 °C 30 30
P013
Contact sensor: hysteresis for limit temperatures
P010, P011, P012, P014
10 0 255 K/10 10 10
P014
Contact sensor: limit value temperature to activate
fan stages in cooling mode
18 0 255 °C 18 18
P015 Function of input AI1 0 0 19 - 0 0
P016 Function of input AI2 0 0 19 - 0 13
P017 Function of input AI3 0 0 9 - 0 0
P018
Temperature increase of cooling setpoint in Eco
mode
30 0 255 K/10 30 30
P019
Temperature decrease of heating setpoint in Eco
mode
30 0 255 K/10 30 30
P020 ADC limit coefficient 6 0 15 - 6 6
P021 ADC average coefficient 6 0 15 - 6 6
P022
Activation / deactivation of sun symbol in Comfort
mode
0 0 1 - 0 0
P023 Difference for compensation in cooling 0 -99 127 K/10 0 0
P024 Coefficient for compensation in cooling 0 -20 20 1/10 0 0
P025 Difference for compensation in heating 0 -99 127 K/10 0 0
P026 Coefficient for compensation in heating 0 -20 20 1/10 0 0
P027
Fan setting: maximum run-time for manual fan
mode
0 0 255 min 0 0
P028
Rinsing function: fan stage during the purging func-
tion
2 1 5 - 2 2
P029 Activation of continuous fan mode 0 0 1 - 0 0
9
Parameter key Katherm HK, SAP no. 9001380, date 10.07.2020
10
Parameter key Katherm HK E, SAP no. 9001631, date 29.10.2021
