Katherm HK
Assembly, installation and operating instructions
40
Katherm HK, KaControl version (*C1)
Trench
length
Number of
fans
Nominal voltage
[V DC]
Mains fre-
quency [Hz]
Nominal
power [W]
Nominal
current
[A]
Ri analogue
input [kΩ]
IP class Protection
class
915 1 (3600) 230 50 7 0.82 20 IP00 I
1200 1 (6000) 230 50 12 0.12 20 IP00 I
1700 1 (10800) 230 50 19 0.17 20 IP00 I
2000 2 (6000. 6000) 230 50 23 0.24 20 IP00 I
2500 2 (10800. 6000) 230 50 30 0.29 20 IP00 I
3000
2 (10800.
10800)
230 50 36 0.34 20 IP00 I
Tab.11: Maximum electrical connection values Katherm HK 320/130, 245/160
Trench
length
Number of
fans
Nominal voltage
[V DC]
Mains fre-
quency [Hz]
Nominal
power [W]
Nominal
current
[A]
Ri analogue
input [kΩ]
IP class Protection
class
915 1 (3600) 230 50 530 2.30 20 IP00 I
1200 1 (6000) 230 50 1030 4.60 20 IP00 I
1700 1 (10800) 230 50 1030 4.60 20 IP00 I
2000 2 (6000. 6000) 230 50 1030 4.60 20 IP00 I
2500 2 (10800. 6000) 230 50 1540 6.90 20 IP00 I
3000
2 (10800.
10800)
230 50 1540 6.90 20 IP00 I
Tab.12: Maximum electrical connection values Katherm HK 320 E/130
Trench
length
Number of
fans
Nominal voltage
[V DC]
Mains fre-
quency [Hz]
Nominal
power [W]
Nominal
current
[A]
Ri analogue
input [kΩ]
IP class Protection
class
950 1 (380) 230 50 13 0.12 20 IP00 I
1200 1 (630) 230 50 19 0.16 20 IP00 I
1700 2 (630. 380) 230 50 29 0.22 20 IP00 I
2000 2 (630. 680) 230 50 35 0.26 20 IP00 I
2500
3 (630. 680.
380)
230 50 47 0.34 20 IP00 I
3000
3 (730. 730.
730)
230 50 53 0.38 20 IP00 I
Tab.13: Maximum electrical connection values Katherm HK 290/160
Trench
length
Number of
fans
Nominal voltage
[V DC]
Mains fre-
quency [Hz]
Nominal
power [W]
Nominal
current
[A]
Ri analogue
input [kΩ]
IP class Protection
class
950 1 (380) 230 50 12 0.11 20 IP00 I
1200 1 (630) 230 50 22 0.21 20 IP00 I
1350 1 (780) 230 50 27 0.26 20 IP00 I
1850 2 (780. 730) 230 50 39 0.37 20 IP00 I
2250 2 (780. 780) 230 50 54 0.52 20 IP00 I
Tab.14: Maximum electrical connection values Katherm HK 360/210
