Katherm HK
Assembly, installation and operating instructions
63
Fig.20: Climate controller type 196000148943
Climate controller, white, type 196000148943
with Modbus interface
for 2- and 4-pipe applications, surface-mounted wall installation on a flush-
mounted box with a visually unobtrusive design with 2.5” LCD display and
high-quality glass finish with capacitive keys
automatic LED backlight
parametrisable language: German or English
timer program with 3 time channels, each with 4 switch-over points
Modbus-RTU interface as a slave device
option to connect an external room sensor
2 control inputs (functions parametrisable, e.g. window contact, presence
detector, heating/cooling switchover)
For use with Katherm HK, max. 4 units.
Fig.21: Climate controller type 196000148944
Climate controller, black, type 196000148944
with Modbus interface
for 2- and 4-pipe applications, surface-mounted wall installation on a flush-
mounted box with a visually unobtrusive design with 2.5” LCD display and
high-quality glass finish with capacitive keys
automatic LED backlight
parametrisable language: German or English
timer program with 3 time channels, each with 4 switch-over points
Modbus-RTU interface as a slave device
option to connect an external room sensor
2 control inputs (functions parametrisable, e.g. window contact, presence
detector, heating/cooling switchover)
For use with Katherm HK, max. 4 units.
Room temperature controller type 146928
Room temperature controller for 2- and 4-pipe applications, surface-moun-
ted wall installation on a flush-mounted box
with setpoint display by threshold arrows
heating or cooling via active 0-10 V signals
option for external room sensor connection
digital input for ECO operation
For use with Katherm HK E, max. 5 units
