Kane KANE988 - Analyser Layout and Components

ANALYSER LAYOUT
Power On / Off
Function Keys x 3
- see below
Scroll Up
Water trap
8 KANE988 MANUAL
Flue Temperature T1
Store / F2 Pump On / Off
Pressure connection P1
OK / Enter
Particle
filter
Analyser Connections
- see section 2
Battery charger
connection
Home
Back / Delete
Scroll Down
Flue gas inlet
Print / F1
Fit spigot probe to
hose before
connecting to
Flue gas inlet
Exhaust port
DO NOT
COVER
Pressure connection P2
Flue Temperature T2
