OPERATION MANUAL
AF INTEGRA / AF-H INTEGRA ELT
PAGE: 107
JUN 20/2013
H. Transmitter Technical Specifications
TYPE
• Two-frequency ELT
(121.5 / 406.037 MHz)
• Automatic Fixed
• COSPAS-SARSAT Class
INTEGRA AF (ER)/AF-H (ER):
Class I, -40°C to +55°C.
INTEGRA AF/AF-H:
Class II, -20°C to +55°C.
406 MHz TRANSMISSION
• Frequency: 406.037 MHz+/-1 kHz
• Output power: 5W (37 dBm +/- 2 dB)
• Modulation type: 16K0G1D
(Biphase L encoding)
• Transmission duration:
520ms (long message) every 50 s.
• Autonomy
INTEGRA (ER): 24 Hours @-40°C
INTEGRA: 24 Hours @-20°C
121.5 MHz TRANSMISSION
• Frequency:
121.5 MHz +/- 6 kHz
• Output power:
50 to 400 mW
(17dBm to 26 dBm), typical 100 mW
• Modulation type: 3K20A3X
• Modulation rate: > 85 %
• Frequency of modulation signal:
1600 Hz to 300 Hz with decreasing
sweep
•
Autonomy
INTEGRA (ER):
over 48 hours@-40°C
INTEGRA:
over 48 hours@-20°C.
G-SWITCH SENSOR
Mechanical G-switch sensor compliant
with EUROCAE ED62 specifications.
RF Fied strenght limits
INTEGRA (ER): 0.471 V/m
INTEGRA: 0.474 V/m
CONTROLS
• ARM / OFF / ON switch
• DIN12 socket for RCP and pin
programming option.
• Bright red visual indicator
• Buzzer
• BNC antenna connector
BATTERY
KIT BAT200, P/N: S1840510-01
LiMnO
2
two-element battery for
transmitter power supply
Battery expiry date: 7 years from date of
cell manufacturing
HOUSING
Material: Polycarbonate
Color: Yellow (color compounded)
Transmitter dimensions:
131 x 86 x 75.4 mm
( 5.157 x 3.385 x 2.968 inches)
Weight:
• AF: typical 755 g. (1.66 lb).
• AF-H: typical 760 g. (1.67 lb).
Tightness: O-ring
ENVIRONMENTAL CONDITIONS
RTCA DO-160F / EUROCAE ED14F
Section 4 to 26:
INTEGRA AF / AF (ER)
[ED62A]X[ED62A]A[ED62A][R(C&C1)]X
WXXXSZXXXZ[ED62A]B[XXG33]XXA
[ED62A]
INTEGRA AF-H / AF-H (ER)
[ED62A]X[ED62A]A[ED62A][U(G)]XWXX
XSZXXXZ[ED62A]B[XXG33]XXA
[ED62A]
QUALIFICATIONS
ETSO-2C91a & ETSO-2C126 / TSO-
C126a
FOR USE OUTSIDE OF THE USA OR
EASA RULES, CONTACT YOUR
LOCAL CIVIL AVIATION AUTHORITY.
