KAR-TECH MICRO - HISTOGRAM

MICRO REMOTE
12
this PWM output
b. ROLLOVER RIGHT –
Select to adjust
this PWM output
c. IDLE LOW – Select
to adjust this PWM
output
d. IDLE HIGH –
Select to adjust
this PWM output
2. Select the parameter of
the output to change
from the second drop-
down menu
a. Min – Minimum
percent (%) of PWM
b. Max – Maximum
percent (%) of PWM
c. Ramp Up – Time in
seconds to go from
Min to Max PWM
d. Ramp Down – Time
in seconds to go
from Max PWM to
zero
e. Frequency – Dither
frequency to valves
in Hz (Change
affects all outputs)
3. Enter the new value in
the new value box
4. Tap the Save button to
send the setting to
memory
The lines to the right of the
parameter indicate the
present value of the output (if
active).
Tap the Factory Settings
button to return all outputs to
standard values. Tap HOME to
quit calibration and return to
the main menu.
HISTOGRAM
Tap the Histogram icon to see
a set of screens that show
which error codes are active
and how many times the
