KAR-TECH MICRO - WIRING

MICRO REMOTE
17
WIRING
COLOR DESCRIPTION
RED 14GA GXL POWER (9-30V)
BLACK 14GA GXL GROUND
WHITE 14GA GXL ROLLOVER LEFT PWM OUTPUT
WHITE 14GA GXL ROLLOVER RIGHT PWM OUTPUT
BLUE 18GA GXL IDLE LOW PWM OUTPUT
BROWN 18GA GXL IDLE HIGH PWM OUTPUT
WHITE 14GA GXL BOOM OUTPUT
PIN DESCRIPTION
1 POWER (9-30V)
2 RS-232 RX
3 RS-232 TX
5 GROUND
DB9 CONNECTOR
