2 English 5.906-468.0 Rev. 00 (02/09)
Contents
1 Preface
4
2 Safety instructions
4
2.1 Safety Devices 4
3 Technical Features
4
3.1 Drive 4
3.2 Brush system 4
3.3 Water System 4
3.4 Suction system 4
3.5 Electrical system 4
4 Setup and function
5
4.1 Front view 5
4.2 Rear view 6
4.3 Control terminal 8
4.3.1 Operating elements and displays 8
4.3.2 Operating panel from below 8
4.3.3 Drive control 8
4.4 Display controls 9
4.4.1 Open the operator menu 9
4.4.2 Open the setup menu 10
4.4.3 Open the debug mode 11
4.5 Circuit board (A1) 12
4.6 Water filling system (option) 13
4.7 Water filter 13
4.8 Drain tap for fresh water 13
4.9 parking brake 13
4.10 Vacuum bar 14
4.11 Cover opened. 14
4.12 Battery 15
4.13 Water stop valve 15
4.14 Detergent dosing pump (DOSE) 16
4.15 Raise/lower brush head 17
4.16 Water pump 18
4.17 Discharge flag against static electricity 18
3.1 Drive 4
4.19 Suction turbine 18
4.20 Brush head (BD model) 19
4.21 Brush head, BR model 19
5 Basic settings and service procedures
20
5.1 Replace filling system 20
5.2 Setting the vacuum Bar 20
5.3 Clean/replace the vacuum lips 21
5.4 Check/replace the support roller on the vacuum bar. 21
5.5 Removing the suction turbine 21
