Kärcher CV 38/2 Service Manual

English 5.906-485.0 Rev. 00 (05/09) 3
Good service work requires extensive and practice-oriented train-
ing as well as well-structured training materials.
Hence we offer regular basic and advanced training programmes
covering the entire product range for all service engineers.
In addition to this, we also prepare service manuals for important
appliances - these can be initially used as instruction guides and
later on as reference guides.
Apart from this, we also regular information about product en-
hancements and their servicing.
If you should require supplements, have corrections or questions
regarding this document, please address these citing the following
subject to:
international-service@de.kaercher.com
The responsible product specialist will take care of your issue.
Copying and duplication of texts and diagrams as well as
third-party access to this information is permitted only with
the explicit permission of the company:
Alfred Kärcher GmbH & Co. KG
P O Box 160
D - 71349 Winnenden
www.kaercher.com
 Danger
Immediate danger that can cause severe injury or even death.
몇 Warning
Possible hazardous situation that could lead to severe injury or
even death.
Caution
Possible hazardous situation that could lead to mild injury to per-
sons or damage to property.
Structure:
– Two-motoric brush vacuum
– Height adjustable handle
– The height of the brush head can be adjusted to match the pile
height of the carpet (with indicator lamp).
– 3-fold filter: Dust filter (fleece filter), motor protection filter, ex-
haust filter
– Filter filling display
– CV 38/2: Working width 335 mm (13.2 in.)
– CV 48/2: Working width 430 mm (16.9 in.)
Drive:
– Suction turbine (blower motor)
– The second motor drives the brush roller by means of a toothed
gear (brush motor).
1 Preface
Subject: Fall 108579
2 Safety instructions
2.1 Hazard levels
3 Technical Features

Kärcher CV 38/2 Specifications

General

Motor power	- W
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	850 W
Annual energy consumption	37.4 kWh
Airflow	40 l/s
Product type	Upright vacuum
Dust capacity	5.5 L
Product color	Black, Grey
Tube material	-
Dust container type	Dust bag
Standard nominal width	- mm
Noise level	80 dB
Cleaning surfaces	Carpet
Vacuum air filtering	HEPA
Dirt separating method	Filtering
Working width (standard brush)	380 mm
Cord length	12 m

Weight and Dimensions

Depth	391 mm
Width	351 mm
Height	1215 mm
Weight	9500 g
Weight (without accessories)	8700 g
