Kärcher CV 38/2 Service Manual

4 English 5.906-485.0 Rev. 00 (05/09)
1 Brush cover
2Brush
3 Brush head
4 Indicator bundle
(CV 38/2 only)
5 Unlocking brushg head
6 Upholstery nozzle
7 Crevice nozzle
8 Handle adjustment
9 Indicator lamp on the filter housing (red)
10 Handle
11 Suction hose
12 Suction pipe
13 Power switch
14 Filter bag
15 Filter cover
16 Motor filter
17 Blower filter
18 Pile height adjustment knob
(Standard series in position 2)
19 Indicator lamp - Electronic brush control (orange)
4 Parts of the system
18
19
4
3
1
2
10
11
12
13
14
15
16
17
9
8
5
7
6

Kärcher CV 38/2 Specifications

General

Motor power	- W
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	850 W
Annual energy consumption	37.4 kWh
Airflow	40 l/s
Product type	Upright vacuum
Dust capacity	5.5 L
Product color	Black, Grey
Tube material	-
Dust container type	Dust bag
Standard nominal width	- mm
Noise level	80 dB
Cleaning surfaces	Carpet
Vacuum air filtering	HEPA
Dirt separating method	Filtering
Working width (standard brush)	380 mm
Cord length	12 m

Weight and Dimensions

Depth	391 mm
Width	351 mm
Height	1215 mm
Weight	9500 g
Weight (without accessories)	8700 g
