English KMR 1000 T 26
Changing the fuse
Loosen the fuse housing from the
recess.
! Replace defective fuses
! Retighten the fuse housing in the
recess
♦ Use only fuses with the same
current rating.
FAULT INDICATIONS
Machine will not start
• Lift the sweeping drum and set the
"parking brake" operation mode
• Fill fuel tank
• Check the fuse
• Charge the battery
• Clean or replace the spark plug
• Replace the safety switch
• Notify Kärcher customer service
Motor running but machine not
moving
• Tighten or replace the traction belt
• Notify Kärcher customer service
Machine not sweeping properly
• Check the sweep roller
• Make the coarse dirt flap movable
• Tighten or replace the belts
• Notify Kärcher customer service
Machine making dust
• Make the coarse dirt flap movable
• De-dust or replace the dust filter
• Adjust or replace the sealing strip
• Clean the suction hose
TECHNICAL DATA
Unit data
Length x width x height
1900 x 870 x 930 mm
Permitted total weight 300 kg
Net weight 180 kg
Travel- and sweeping
speed 7 km/h
Width of sweeping path
without side brush 700 mm
Width of sweeping
path with side brush 900 mm
Climbing ability max. 15 %
Area performance
Without side brush 4900 m²/h
With side brush 6300 m²/h
Debris container volume 60 l
Filter surface area 4 m²
Category M
Degree of Protection (IEC),
drip proof IPX 3
Roller
Diameter 220 mm
Width 700 mm
Side brush
Diameter 450 mm
Engine
Type Briggs&Stratton,
1-cyl.-four stroke
Displacement 189 cm³
Power (at 3000 1/min) 4,8 kW
Operating engine
speed 2800 1/min
Fuel, normal (lead-free) 3,8 l
Engine oil, API, SE, SG
0,6 l
SAE 15W40
Spark plug, Champion RC12YC
Noise emission
Sound level
(EN 60704-1) 82 dB(A)
Guaranteed noise
level (2000/14/EU) 99 dB(A)
Machine vibration
Total vibration value (ISO 5349)
Upper limbs < 2,5 m/s²
Feet/seat area 0,6 m/s²
Battery
12V, 14 Ah
Ambient conditions
Temperature -5 to + 40° C
Humidity,
non-condensing 10 - 90 %
Rated volumetric flow 90 l/s
Rated vacuum 12 mbar
