MAINTENANCE
DAILY
Hydraulic Oil Level
* Always clean around fill plug before removing.
* DO NOT OVER FILL.
* DO NOT OPERATE the machine when oil level
is above FULL (H) or ADD (L) marks.
1. Place the machine on level ground and lower the
bucket to the ground, with the arm and bucket
cylinders fully retracted, as shown.
2. Maintain the oil level between the FULL (H)
and ADD (L) marks on the level gauge.
3. Slowly loosen the fill plug o relieve any and
remove it to add oil if necessary.
4. Clean and install the fill plug. To pressurize the
hydraulic tank, refer to “Change Hydraulic Oil”
section.
Fill Fuel Tank
Fuel can be added to the tank by removing the fill
cap on top of the fuel tank. Do not remove strainer
in the fill port when fill fuel tank.
After completion of refueling, be sure to lock the fuel
tank cap to protect against vandalism.
Dust Indicator
Check the air filter dust indicator. If the indicator is
in the red zone, clean or replace the element.
See Service the Filter Elements.
After servicing, reset the dust indicator pushing in
the reset button.
CAUTION
Bucket position at the time of
checking the hydraulic oil level.
Hydraulic
oil tank
➁
Fill plug
➀
Oil level
gauge
➂
Drain plug
H
L
➁
Strainer
Reset button
Indicator
RelieseRed signal
To Next Page
