7 Technical data
FOCUS 33
Nominal Shortest Irradiation Time 0.02 S
Exposure Time Range 0.02 - 3.2 S
Exposure Time Range In Aec Mode 0.02- 1.6 S
BEAM LIMITING DEVICE
Cone dimensions Round: 60 mm
Rectangular: 35x45 mm / 28x36 mm
PHYSICAL MEASURES AND AMBIENT TEMPERATURES:
Focal length (Standard/Long) 229 mm (9”) / 305 mm (12”)
Installation Standard wall mount Optional
base for free standing unit
Height x Width x Depth (mm) Unit: 1059 mm x 279 mm x 946/
1096/1346 mm
Tube head assembly: 112 mm x
260 mm x 201 mm
Weight Unit: approximately 30 kg
(66 pounds)
Tube head assembly:
approximately 4.5 kg (10 pounds)
Type and length of the cable of
the remote exposure switch
Length approximately 10 m
(32.5 feet),
RJ-45 plug at both ends (8 wires)
Transportation and Storage -40°...+70°C (-40F...+158F),
RH 10...100%
Operating environment +10°...+40°C (+50F...+104F),
RH max. 70%,
700 – 1060 mbar
