8 User's statement
FOCUS 47
WAIT TIMES BETWEEN EXPOSURES
Below are the wait times for different exposures.
DIMENSIONAL OUTLINE OF THE TUBEHEAD
Fig 8.4. Tubehead dimensions and the location of the focal spot
Exp. time Wait time Exp. time Wait time
0.02s 10s 0.32s 10s
0.03s 10s 0.40s 10s
0.04s 10s 0.50s 10s
0.05s 10s 0.63s 19s
0.06s 10s 0.80s 24s
0.08s 10s 1.00s 30s
0.10s 10s 1.25s 50s
0.12s 10s 1.60s 64s
0.16s 10s 2.00s 80s
0.20s 10s 2.50s 100s
0.25s 10s 3.20s 128s
