49
0V (COM)
+2,5V
+B
t
0V (COM)
+2,5V
+A
1Vss
t
Signals Format of the analog channels
1 wave cycle per increment
For a 1024 ppr encoder this is equal to
360° /1024 = 0.352° mechanical revs.
Installation and Connection
