GB - 9
Inverter size 12 13 14 15 16
Housing size E
Phases 3
Output rated power [kVA] 6.6 8.3 11 17 23
Max. rated motor power [kW] 4 5.5 7.5 11 15
Output rated current [A] 9.5 12 16.5 24 33
Output rated current UL [A] 7.6 11 14 21 27
Max. short time current [A] 17 21.6 29.7 36 49.5
OC-tripping current [A] 21 25.9 35.6 43 59
Rated input current [A] 13 17 23 31 43
Rated input current UL [A] 10.6 15.4 19.6 27.3 35
Max. permissible main fuse type gG [A] 20 25 25 35 50
Rated switching frequency [kHz] 16 16 8 4 2
Max. switching frequency [kHz] 16 16 16 16 4
Power dissipation at nominal operating [W] 300 250 320 350 330
Power dissipation at DC operating [W] 285 230 295 310 275
Minimum braking resistor [Ω] 39 39 39 39 25
Maximal braking current [A] 21 21 21 21 32
Rated input voltage [V] 400 (UL: 480)
Input voltage range U
in [V] 305…528 ±0
Mains frequency [Hz] 50…60 ±2
output voltage [V] 3 x 0…U
in
Output frequency
1)
[Hz] 0…400
Max. motor line length (shielded) [m] 100
For use in USA
Max. mains fuse type RK5 [A] 15 25 30 40 50
Max. input fusing MMC type "E"
2)
[A] 16 25 30 40 50
1) The actual output frequency is depending on the parameterisation. The output frequency is to be limited in such
way that 1/10 of the switching frequency is not exceeded. Output frequencies above 599 Hz are possible by
changing the operating mode at control type „BASIC“ (xxF5Bxx-xxxx) as well as for special devices on request.
This devices are subject to export authorisation according to entry 3A225 Annex I of the Dual-Use Regulation
and they are labeled accordingly on the delivery note. The output frequency is limited to max. 599 Hz for all other
control types. This devices are not subject to export authorisation.
2)
Use E-MMC/ Type E - Manual Motor Controller according to UL508 / Class NKJH only. The following types are accepted:
Manufacturer UL - File Type Required terminal line adaptor
Siemens E 156943
3RV1021-1xA10 3RV1928-1H
3RV1031-4xA10 –
ABB Stotz E 195536
MS325-xx S3-M3
MS450-xx –
Rockwell / Allen
Bradley
E 205542
140M-C2E-Bxx or Cxx –
140M-F8E-Cxx –
Moeller E 123500 PKZM0-xxE (only up to 25 A) BK25/3 - PKZ0-E
Where x or xx means that here current rating or letter for current rating is given.
Use only in mains Wye 480/277 V. Delta grounding is not permitted.
2.3.2 400 V class
