3.6 Setting Up 3.6
Once the Evolution has been set up all that needs to be done is build the level of the
worktop surface up by 15 - 16mm ( 5/8”) in the area behind the cutter. If you have
mounted the cutter away from the edge of the worktop you can build this area up as well.
Either solid boards or thin boards supported on packing strips can be used.
NOTE: If your worktop is not flat and the Jacking Screws have been set to
compensate for it, should a solid board be used to build up the worktop and screwed
down unto it, it could alter the levels of the bench and affect the clamping. It is better
to use an adhesive (a few spots of silicone adhesive/sealer generally works well)
or double sided sticky tape to stop it sliding out of position.
➤
