4.5 Operation 4.5
USING THE TEXTILE CUTTING ATTACHMENT
The Evolution is supplied with an attachment that fits onto the cutting head to enable it to
cut textiles. It uses a circular blade to press down onto the surface of the textile held
over a plastic strip embedded in the base of the machine.
Firstly, raise the Cutter Bar using either Lift & Hold Lever, then Loosen both of the Hinge
Knobs until the underside of the knob clears its’ location recess, Push the Cutter Bar
away from you until the underside of the knob is positioned over the middle recess and
tighten the knob holding the knurled end of the Hinge Bolt to prevent it turning. Repeat at
the other end. The Cutter Bar is now positioned over the plastic Cutting Strip.
The third (furthest) position is also for cutting textile but uses a different part of the
Cutting Strip should it become worn. The Cutting Strip can also be removed, turned
around or flipped over then replaced to further extend its life. Replacement Cutting Strips
are available from your Keencut agent.
➤
➤
