KEEWAY ARN150 - Shifting Gears Information; Sprocket Information; Chain Information

18
Shifting gears inforamtion
Gear down
ratio
Gear Gear qty. Gear QTY.
2.8 A
1
15 A
2
42
3.077 B
1
13 B
2
40
GEAR INFORMATION
NO. GEAR QTY. POSITION
1
Kick starter gear
38 ENGINE
2
Kick starter transition
small gear
13
ENGINE
3
Kixk starter transition big
gear
49
ENGINE
4
Crank kick starter driven
gear
20
ENGINE
5
Starting motor drvie gear
9
ENGINE
6
Electricity starter
transition gear
54/13
ENGINE
7
Clutch gear
52
ENGINE
SPROCKET INFORMATION
No.
No.No.
No. Sprocket wheel
Sprocket wheelSprocket wheel
Sprocket wheel
QTY. POSITION
1
Right crank oil pump driver
sprocket wheel
17 ENGINE
2 Oil pump sprocket wheel
19 ENGINE
3
Left crank atmolysis shaft
driver sprocket
17 ENGINE
4 Atmolysis shaft sprocket
34 ENGINE
CHAIN INFORMATION
NO. CHAIN NODE POSITION
1 ATMOLYSIS SHAFT CHAIN 90 ENGINE
2 OIL PUMP CHAIN 42 ENGINE
