g ．
．．
． R e q u i r e m e n t f o r m a i n e l e c t r i c c o m p o n e n t s p e c i f i c a t i o n
Storage battery charging system
ITEM SPECIFICATION
Capacity 12V-2.5AH（KS）/7AH（KS）
Specific gravity (27
℃)
Condition for full
charge
1.220-1.240
＜1.220
Current for charge 0.25A/0.7A
Storage
battery
Time for charge 8-12 hours
Capacity 114W（at 5000RPM）
Charger
Ignition coil
resistance
（20℃/68°F）
Between black line and
black/white
≤2Ω
Lamp line Yellow and
green/white
≤2Ω
Adjust the output of rectifier：
Adjust output voltage to be less than 14.5V and supply the voltage to lighting circuit;
Adjust the DC charging voltage of storage battery to be more than 11.5V;
Adjust the DC charging current of storage battery (at 5000rpm) to be 0.6~2A.
