KEEWAY ARN150 - Install Vehicle Body

48
5 ．
．．
． I n s t a l l v e h i c l e b o d y
a ．
．．
． S p e c i f i e d f i x i n g t o r q u e
NO.
ITEM QTY. FIXING TORQUE
FRONT WHEEL/FRONT ABSORBER
1 Front wheel axis locknut 1 55-62Nm
2
Fixing boblt between front absorber and support under
connecting board assy.
4 37-44N.m
3 Fixing bolt for disc brake and front absorber 2 22-29N.m
Handlebar
1
Fixing bolt for handlebar and supporting under connecting
board
1 37-44N.m
Frame
1 Fixing bolt for frame and engine bracket 45-58N.m
Fixing bolt for frame and rear absorber
1
Rear wheel/rear absorber
2 37-44N.m
2 Rear wheel locknut 2 37-44N.m
Fixing bolt for left, rear absorber and engine
1
Fixing bolt for right, rear absorber and muffler connecting
board
1 100-130Nm
2
Engine
1 22-29N.m
Fixing bolt for engine and muffler
1 Fixing bolt for engine and engine bracket 2 22-29N.m
2
FRONT WHEEL/FRONT ABSORBER
1 37-44N.m
