M7i WHEELCHAIR-ACCESSIBLE TOTAL BODY TRAINER
07
To position the M7i at the desired location, carefully tilt the M7i toward the rear until the transport wheels make contact with
the oor to transport.
NOTE: Carefully remove all parts from the box and check for any damage or missing parts (see “Parts List,” page 8). If parts are
damaged or missing, contact your local dealer, distributor, or Keiser Customer Support by telephone at 1 559 256 8000.
The minimum amount of required free space around
the M7i is 36 inches (914 mm), see Figure 1. When M7i
machines are positioned adjacent to each other, the
free space may be shared. Free space at the rear of
the M7i is not required when the M7i is positioned
against a wall.
1 2 3
M7i Wheelchair-accessible Total Body Trainer
EQUIPMENT SPECIFICATIONS
TRAINING SPACE
ASSEMBLY
TWO-PERSON PROCEDURE: Due to the size and weight of the equipment, help is required to safely and successfully
complete installation.
UNPACKING
Position the shipping box in a cleared area. Follow unpacking steps 1–3 below.
TOOLS AND MATERIAL REQUIRED
5 mm Allen WrenchSafety Blade Dry Soft Cloth
or Towel
Scissors
Figure 1. Training Area
36 in (914 mm) 36 in (914 mm)
36 in (914 mm)36 in (914 mm)
38.5 - 48.5 in
(978 - 1,232 mm)
28 in (711 mm)
REAR
FRONT
TRAINING AREA
FREE AREA
Height Depth Width Weight
44 in
(1,118 mm)
38.5 in
(978 mm)
28 in
(711 mm)
142 lbs
(65 kg)
User height requirement: 48 in (1,219 mm) or taller
Arm reach minimum requirement: 12 in (305 mm)
