Keithley 2001 Quick Reference Guide

23
Table 10. CONFIGURE TRIGGER menu structure
Menu item Description
MEASURE
SOURCE
IMMEDIATE
EXTERNAL
MANUAL
GPIB
TRIGLINK
TIMER
HOLD
DELAY
COUNT
INFINITE
ENTER-CHAN-COUNT
CONTROL
SOURCE
ACCEPTOR
Measure layer menu:
Select measure source:
Use to make measure-
ments immediately.
Use external triggers to
control measuring.
Use TRIG key to control
measuring.
Use bus triggers to control
measuring.
Use Trigger Link triggers to
control measuring. Enter
Trigger Link mode and
lines.
Use a timer to control mea-
suring and enter interval
between triggers (0.001-
999999.999sec).
Use to hold up the mea-
surement in the measure
layer.
Use to delay measurement in
the measure layer (0.001-
999999.999sec).
Define number of measure-
ments to make:
Repeat measuring indefi-
nitely.
Count = use defined value
(1-99999).
Select trigger control mode:
Enable Source Bypass.
Disable Source Bypass.

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
