Keithley 2001 Quick Reference Guide

24
SCAN
SOURCE
IMMEDIATE
EXTERNAL
MANUAL
GPIB
TRIGLINK
TIMER
HOLD
DELAY
COUNT
INFINITE
ENTER-SCAN-COUNT
CONTROL
SOURCE
ACCEPTOR
Scan layer menu:
Select scan source:
Use to pass operation
immediately into the
measure layer.
Use external triggers to
control scanning.
Use TRIG key to control
scanning.
Use bus triggers to control
scanning.
Use Trigger Link triggers to
control scanning. Enter
Trigger Link lines.
Use a timer to control
scanning and enter inter-
val between scans
(0.001-999999.999sec).
Use to hold up the mea-
surement in the scan
layer.
Use to delay scan in the scan
layer (0.001-
999999.999sec).
Define number of scans to be
performed:
Repeat scanning indefi-
nitely.
Count = user defined value
(1-99999).
Select trigger control mode:
Enable Source Bypass.
Disable Source Bypass.
Table 10. CONFIGURE TRIGGER menu structure
(cont.)
Menu item Description

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
