Keithley 2001 Quick Reference Guide

25
ARM
SOURCE
IMMEDIATE
EXTERNAL
MANUAL
GPIB
TRIGLINK
HOLD
COUNT
INFINITE
ENTER-ARM-COUNT
CONTROL
SOURCE
ACCEPTOR
Arm layer menu:
Select arm source:
Use to arm meter immedi-
ately and pass operation
into the scan layer.
Use external triggers to arm
meter.
Use TRIG key to arm
meter.
Use bus triggers to arm
meter.
Use Trigger Link triggers to
arm meter. Enter Trigger
Link lines.
Use to hold up the mea-
surement in the arm
layer.
Define number of times to
arm meter:
Continuously re-arm meter.
User defined count value
(1-99999).
Select trigger control mode:
Enable Source Bypass.
Disable Source Bypass.
HALT Use to halt triggers. Press TRIG
key to resume triggering.
Table 10. CONFIGURE TRIGGER menu structure
(cont.)
Menu item Description

Keithley 2001 Specifications

General

Model	2001
Category	Multimeter
Manufacturer	Keithley
Type	Digital Multimeter
Digits of Resolution	7.5
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
Frequency Range	3 Hz to 500 kHz
Connectivity	GPIB, RS-232
Display	VFD
Resistance Accuracy	0.008% + 2.0 mΩ
Frequency Accuracy	±0.01%
DC Current Range	10 μA to 3 A
AC Current Range	10 μA to 3 A
Power Supply	100 V to 240 V AC, 45 Hz to 66 Hz
